Full Specs & Features
Width : 107' 10"
First Floor: 2954 sq/ft
Garage: 900 sq/ft height 8'
Second Floor: 875 sq/ft height 9'
Storage: 450 sq/ft
Roof Type : Shingle
Framing : Block (1st Story)/ Wood – 2x6 (2nd Story)
Formal Dining Room
Formal Living Room / Parlor
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Family Room Keeping Room
Main Floor Laundry
Master Sitting Area
Open Floor Plan
Storage Area
Vaulted / Cathedral Ceilings
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
Outdoor Kitchen Grill
Bedroom 2:
width 14' 4" x depth 12' 3"
Bedroom 3:
width 11' 4" x depth 12'
Bedroom 4:
width 11' 4" x depth 12'
Bonus Room:
341 sq/ft width 20' 2" x depth 16'
Covered Front Porch:
353 sq/ft
Covered Rear Porch:
368 sq/ft
Den/ Study:
width 11' x depth 13' 7"
Dining Room:
width 12' 10" x depth 13' 11"
Family Room:
width 15' 6" x depth 21' 8"
Garage:
900 sq/ft width 26' x depth 32'
Living Room:
width 12' x depth 12' 2"
Master Bedroom:
width 16' 1" x depth 23' 11"
Storage:
450 sq/ft
Floor Plan - Other Floor
Floor Plan - Other Floor
Floor Plan - Main Floor
Floor Plan - Upper Floor
In addition to the house plans you order, you may also need a site plan that shows where the house is going to be located on the property. You might also need beams sized to accommodate roof loads specific to your region. Your home builder can usually help you with this. You may also need a septic design unless your lot is served by a sanitary sewer system. Many areas now have area-specific energy codes that also have to be followed. This normally involves filling out a simple form providing documentation that your house plans are in compliance.
To find out what documents you should expect with your house plans, see /help/faq#faq13.
In some regions, there is a second step you will need to take to insure your house plans are in compliance with local codes. Some areas of North America have very strict engineering requirements. Examples of this would be earthquake-prone areas of California and the Pacific Coast, hurricane risk areas of the Florida, Gulf & Carolina Coasts. New York, New Jersey, Nevada, and parts of Illinois require review by a local professional as well. If you are building in these areas, it is most likely you will need to hire a state licensed structural engineer to analyze the design and provide additional drawings and calculations required by your building department. If you aren’t sure, building departments typically have a handout they will give you listing all of the items they require to submit for and obtain a building permit.
Additionally, stock plans do not have a professional stamp attached. If your building department requires one, they will only accept a stamp from a professional licensed in the state where you plan to build. In this case, you will need to take your house plans to a local engineer or architect for review and stamping. In addition, plans which are used to construct homes in Nevada are required to be drawn by a licensed Nevada architect.
