PLAN 20-187
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Dimension
Depth : 43'
Height : 28'
Width : 40'
Height : 28'
Width : 40'
Area
First Floor: 1014 sq/ft height 9'
Garage: 508 sq/ft
Porch: 144 sq/ft
Second Floor: 809 sq/ft
Garage: 508 sq/ft
Porch: 144 sq/ft
Second Floor: 809 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 12:12
Roof Framing : Truss
Roof Type : Shingle
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x4
Framing : Wood - 2x4
Bedroom Features
Upstairs Master Bedrooms
Walk In Closet
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Kitchen Island
Additional Room Features
Den Office Study Computer
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For Narrow Lot
Suited For View Lot
Suited For Narrow Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Rooms
Bathroom 2:
30 sq/ft width 5' 4" x depth 5' 8"
Bathroom 3:
45 sq/ft width 5' x depth 9'
Bedroom 2:
136 sq/ft width 11' 8" x depth 11' 8"
Bedroom 3:
125 sq/ft width 10' x depth 12' 6"
Dining Room:
134 sq/ft width 11' 8" x depth 11' 6"
Foyer:
48 sq/ft width 5' 8" x depth 8' 6"
Garage:
458 sq/ft width 21' 4" x depth 21' 6"
Kitchen:
126 sq/ft width 11' 8" x depth 10' 10"
Kitchen Island:
15 sq/ft width 3' x depth 5'
Living Room:
326 sq/ft width 17' 8" x depth 18' 6"
Master Bathroom:
82 sq/ft width 16' 6" x depth 5'
Master Bedroom:
198 sq/ft width 16' 6" x depth 12'
Master Closet:
46 sq/ft width 6' x depth 7' 8"
Nook:
112 sq/ft width 11' 8" x depth 9' 8"
Utility Room:
38 sq/ft width 5' 8" x depth 6' 10"
What's Included In This Plan Set
- Cover Page: Each home plan features the front elevation and informative reference sections including general notes and design criteria.
- Elevations: Drafted at ¼" scale for the front and 1/8" scale for the rear and sides. All elevations are detailed and an aerial view of the roof is provided, showing all hips, valleys, ridges and framing.
- Foundations: Drafted at ¼" - 1' scale. This plan is designed as a slab foundation. Optional basement or crawl space foundations are available. Basement foundations may require additional engineering for steel beam sizes.
- Main Level Floor Plan: Drafted at ¼" scale. 2" x 4" walls are standard. The detailed drawings include such things as ceiling treatments and header locations.
- Second Level Floor Plan: Drafted at ¼" scale. Drafted to the same degree of detail as the main level floor plan.
- Interior Elevations: Kitchen cabinet elevations are drawn.
- Electrical and Sections: The electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall, stair, brick sections are provided to further explain construction of these areas.
