PLAN 20-189
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 70'
Height : 28'
Width : 53'
Area
First Floor: 1492 sq/ft height 9'
Garage: 487 sq/ft
Second Floor: 805 sq/ft
Roof
Primary Pitch : 12:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x4
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Great Room Living Room
Garage Features
Rear Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Rooms
Bathroom 2:
18 sq/ft width 6' 8" x depth 2' 10"
Bathroom 3:
72 sq/ft width 14' 6" x depth 5'
Bathroom 4:
62 sq/ft width 9' 4" x depth 6' 8"
Bedroom 2:
192 sq/ft width 14' 10" x depth 13'
Bedroom 3:
128 sq/ft width 10' 8" x depth 12'
Bedroom 4:
126 sq/ft width 11' 6" x depth 11'
Dining Room:
150 sq/ft width 14' 4" x depth 10' 6"
Foyer:
36 sq/ft width 7' 4" x depth 5'
Garage:
433 sq/ft width 20' 4" x depth 21' 4"
Kitchen:
252 sq/ft width 12' 4" x depth 20' 6"
Kitchen Island:
15 sq/ft width 3' x depth 5'
Kitchen Island:
15 sq/ft width 3' x depth 5'
Living Room:
315 sq/ft width 20' 4" x depth 15' 6"
Master Bathroom:
113 sq/ft width 6' 8" x depth 17'
Master Bedroom:
227 sq/ft width 14' 8" x depth 15' 6"
Master Closet:
61 sq/ft width 10' 6" x depth 5' 10"
Pantry:
4 sq/ft width 2' 4" x depth 2'
Utility Room:
31 sq/ft width 5' 4" x depth 6'
