PLAN 20-229
Key Specs
2837
sq ft
4
Beds
3
Baths
2
Floors
2
Garages
Cost to Build Reports Only $19.99 for a Limited Time!
This report will provide you cost estimates based on location and building materials.
Get Cost-To-Build Report
Or order by phone: 1-888-447-1946
Questions?
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-888-447-1946
Phone: 1-888-447-1946
Hours: Mon-Fri, 9AM - 8:30PM (EST)
See our Terms & Conditions and Privacy Policy.
PLAN 20-229
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Dimension
Depth : 72'
Height : 31'
Width : 52'
Height : 31'
Width : 52'
Area
First Floor: 2143 sq/ft height 9'
Second Floor: 694 sq/ft
Second Floor: 694 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 12:12
Roof Framing : Truss
Roof Type : Shingle
Secondary Pitch : 12:12
Roof Framing : Truss
Roof Type : Shingle
Secondary Pitch : 12:12
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Framing : Wood - 2x4
Bedroom Features
Guest Suite
Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet
Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Walk In Pantry Cabinet Pantry
Eating Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Family Room Keeping Room
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Suited For View Lot
Outdoor Spaces
Covered Rear Porch
More
Jack & Jill Bath
Rooms
Bathroom 2:
44 sq/ft width 8' 10" x depth 5'
Bathroom 3:
105 sq/ft width 10' 6" x depth 10'
Bedroom 2:
133 sq/ft width 10' 6" x depth 12' 8"
Bedroom 3:
135 sq/ft width 11' 4" x depth 12'
Bedroom 4:
156 sq/ft width 12' 8" x depth 12' 4"
Family Room:
340 sq/ft width 19' 8" x depth 17' 4"
Game Room:
120 sq/ft width 11' 4" x depth 10' 8"
Garage:
77 sq/ft width 20' 4" x depth 3' 10"
Kitchen:
182 sq/ft width 13' 8" x depth 13' 4"
Living Room:
156 sq/ft width 12' 4" x depth 12' 8"
Master Bathroom:
150 sq/ft width 9' 4" x depth 16' 2"
Master Bedroom:
233 sq/ft width 17' 4" x depth 13' 6"
Master Closet:
59 sq/ft width 6' 2" x depth 9' 8"
Nook:
136 sq/ft width 13' 8" x depth 10'
Pantry:
16 sq/ft width 4' x depth 4'
Utility Room:
58 sq/ft width 6' 6" x depth 9'
What's Included In This Plan Set
- Cover Page: Each home plan features the front elevation and informative reference sections including general notes and design criteria.
- Elevations: Drafted at ¼" scale for the front and 1/8" scale for the rear and sides. All elevations are detailed and an aerial view of the roof is provided, showing all hips, valleys, ridges and framing.
- Foundations: Drafted at ¼" - 1' scale. This plan is designed as a slab foundation. Optional basement or crawl space foundations are available. Basement foundations may require additional engineering for steel beam sizes.
- Main Level Floor Plan: Drafted at ¼" scale. 2" x 4" walls are standard. The detailed drawings include such things as ceiling treatments and header locations.
- Second Level Floor Plan: Drafted at ¼" scale. Drafted to the same degree of detail as the main level floor plan.
- Interior Elevations: Kitchen cabinet elevations are drawn.
- Electrical and Sections: The electrical plan shows suggested electrical layout for the main and second level floor plans. Typical wall, stair, brick sections are provided to further explain construction of these areas.
