PLAN 20-231
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 60'
Height : 35'
Width : 64'
Area
First Floor: 2496 sq/ft height 9'
Second Floor: 1348 sq/ft
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Shingle
Secondary Pitch : 12:12
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : 2"x4"
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Butler's Pantry
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Master Sitting Area
Storage Area
Unfinished Future Space
Garage Features
Oversized Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Rear Porch
More
Jack & Jill Bath
Rooms
Bathroom 2:
22 sq/ft width 3' 4" x depth 6' 8"
Bathroom 3:
43 sq/ft width 5' x depth 8' 8"
Bathroom 4:
65 sq/ft width 13' x depth 5'
Bedroom 2:
171 sq/ft width 12' 8" x depth 13' 6"
Bedroom 3:
177 sq/ft width 11' 4" x depth 15' 8"
Bedroom 4:
165 sq/ft width 11' 10" x depth 14'
Dining Room:
217 sq/ft width 12' 8" x depth 17' 2"
Family Room:
340 sq/ft width 17' x depth 20'
Foyer:
142 sq/ft width 7' 6" x depth 19'
Game Room:
345 sq/ft width 16' 4" x depth 21' 2"
Garage:
618 sq/ft width 21' 4" x depth 29'
Kitchen:
268 sq/ft width 19' 2" x depth 14'
Kitchen Island:
6 sq/ft width 2' x depth 3'
Living Room:
198 sq/ft width 14' 8" x depth 13' 6"
Master Bathroom:
246 sq/ft width 17' x depth 14' 6"
Master Bedroom:
253 sq/ft width 17' 6" x depth 14' 6"
Master Closet:
70 sq/ft width 10' 4" x depth 6' 10"
Master Closet Two:
39 sq/ft width 6' x depth 6' 6"
Master Sitting Area:
93 sq/ft width 9' 8" x depth 9' 8"
Pantry:
13 sq/ft width 3' 8" x depth 3' 8"
Study:
180 sq/ft width 12' x depth 15'
Utility Room:
62 sq/ft width 11' x depth 5' 8"
What's Included In This Plan Set
- Foundation Plan(s): This page shows all necessary notations and dimensions including footings, support columns, walls, and excavated/unexcavated areas.
- Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows and doors, fixture locations, and ceiling treatments.
- Exterior Elevations: Views of the home from all four sides showing exterior materials, roof slope, ridge heights, siding and trim notes.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Construction Notes / Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
Plan Set
$1092.25
$1343.00
Foundation
$0.00
$165.75
$165.75
Framing
$0.00
$165.75
Additional Options
$165.75
$140.25
$335.75
$33.15
$140.25
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
