Cars and golf carts are equally welcome in the large garage attached to this
great brick home. The kitchen features tons of counter space, angled double
sinks, and an eat-in bar. The covered back porch can be accessed either through
the master suite or the great room. On your way out, stop and check out the 3'
gas fireplace and boxed ceiling.
Full Specs & Features
Dimension
Depth : 59' 8"
Width : 41' 10"
Width : 41' 10"
Area
First Floor: 1287 sq/ft height 9'
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 10:12
Roof Framing : Conventional
Roof Framing : Conventional
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Split Bedrooms
Formal Dining Room
Formal Living Room / Parlor
Split Bedrooms
Additional Room Features
Den Office Study Computer
Great Room Living Room
Great Room Living Room
Outdoor Spaces
Covered Rear Porch
Rooms
Bedroom 2:
166 sq/ft width 11' 6" x depth 14' 6"
Bedroom 2 Closet:
30 sq/ft width 6' x depth 5'
Bedroom 3 Closet:
30 sq/ft width 6' x depth 5'
Dining Room:
95 sq/ft width 10' x depth 9' 6"
Foyer:
49 sq/ft width 7' x depth 7'
Gathering Room:
269 sq/ft width 16' 4" x depth 16' 6"
Hall Bathroom:
47 sq/ft width 9' 6" x depth 5'
Kitchen:
95 sq/ft width 10' x depth 9' 6"
Master Bathroom:
107 sq/ft width 13' 2" x depth 8' 2"
Master Bedroom:
174 sq/ft width 12' x depth 14' 6"
Master Closet:
66 sq/ft width 9' 6" x depth 7'
Porch - Front:
49 sq/ft width 7' x depth 7'
Porch - Rear:
150 sq/ft width 9' x depth 16' 8"
Storage:
15 sq/ft width 3' x depth 5'
Utility Room:
42 sq/ft width 6' 6" x depth 6' 6"
