Key Specs


1375
sq ft

3
Beds

2
Baths

1
Floors

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.

Plan Description


Welcome home. This beautiful narrow lot home has all the amenities of a home much larger than its modest 1375 square feet. This home features a split bedroom layout, large living, large kitchen and dining, oversized bathrooms and closets and volume ceilings. This home also features an optional carport which allows for rear or side entry. With the many features listed above and much, much more, this home is ready for you and your family.

Floor Plans


Floor Plan - Main Floor Plan
Reverse
Cottage Floor Plan - Main Floor Plan Plan #430-41

Full Specs & Features


Dimension
Depth : 53'
Height : 21' 2"
Width : 30' 10"
Area
Garage: 498 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Garage Ceiling : 9'
Main Ceiling : 9'
Roof
Primary Pitch : 8:12
Roof Framing : stick
Roof Load : 40
Roof Type : gable
Secondary Pitch : 4:12
Exterior Wall Framing
Exterior Wall Finish : Brick/ Siding
Framing : 2"x4"
Insulation : 13
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Main Floor Laundry
Storage Area
Garage Features
Carport Porte Cochere
Rear Entry Garage
Rear Garage
Lot Characteristics
Suited For Narrow Lot
Suited For Sloping Lot
Suited For View Lot
Zero Lot Lines
Outdoor Spaces
Breezeway
Covered Front Porch
Covered Rear Porch
More
Empty Nester
Suited For Vacation Home
Wheelchair Adaptable
Code Compliance
Irc 2003
Structural Information Provided
Foundation Drawing
Structural 1st Floor Framing
Rooms

Bedroom 2:

127 sq/ft width 11' 6" x depth 11'

Bedroom 3:

127 sq/ft width 11' 6" x depth 11'

Covered Front Porch:

138 sq/ft width 17' 6" x depth 8'

Covered Rear Porch:

44 sq/ft width 6' 10" x depth 6'

Hall Bath:

58 sq/ft width 7' 6" x depth 7' 8"

Kitchen/ Dining Room:

269 sq/ft width 18' 4" x depth 14' 8"

Living Room:

252 sq/ft width 16' 10" x depth 15'

Master Bedroom:

182 sq/ft width 13' x depth 14'

Master Bedroom:

68 sq/ft width 8' 6" x depth 8'

Master Closet:

48 sq/ft width 8' 6" x depth 5' 8"

Optional Carport:

441 sq/ft width 21' x depth 21'

Optional Carport Storage:

43 sq/ft width 4' 4" x depth 9' 10"
