PLAN 70-1160
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 37' 8"
Height : 27' 4"
Width : 48' 6"
Area
First Floor: 815 sq/ft height 9' 1"
Garage: 546 sq/ft
Second Floor: 754 sq/ft height 9' 1"
Ceiling
Lower Ceiling : 8'
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Roof Load : 47 psf
Roof Type : Asphalt
Secondary Pitch : 6:12
Exterior Wall Framing
Exterior Wall Finish : Siding, Shake, Stone
Framing : 2x6
Bedroom Features
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Great Room Living Room
Upstairs Laundry
Garage Features
Front Entry Garage
Lot Characteristics
Suited For Narrow Lot
Outdoor Spaces
Covered Front Porch
More
Economical To Build
Rooms
Bedroom 2:
width 10' x depth 11'
Bedroom 2 Closet:
width 6' 7" x depth 2' 1"
Bedroom 3:
width 10' 4" x depth 10' 4"
Bedroom 3 Closet:
width 2' 1" x depth 5' 2"
Covered Front Porch:
width 16' x depth 14' 4"
Dining Room:
width 11' 6" x depth 12'
First Level Hall:
width 10' 7" x depth 3' 7"
Foyer:
width 6' x depth 6' 5"
Garage:
546 sq/ft width 20' 8" x depth 25' 4"
Great Room:
width 13' 6" x depth 17' 4"
Hall Bath:
width 7' 10" x depth 5'
Hall Closet 1:
width 3' 1" x depth 2' 1"
Hall Closet 2:
width 2' 1" x depth 2' 10"
Kitchen:
width 13' x depth 12'
Laundry Room:
width 6' x depth 6' 5"
Master Closet:
width 5' 10" x depth 6' 5"
Master Bath:
width 12' 8" x depth 5' 4"
Master Bedroom:
width 11' 6" x depth 16'
Powder Room:
width 3' 1" x depth 7' 1"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
Plan Set
$973.00
$1016.00
$1215.00
$1215.00
$1921.00
Foundation
$0.00
$395.00
$395.00
Additional Options
$395.00
$80.00
$100.00
$295.00
$39.00
$75.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
