PLAN 72-936
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.Plan Description
Through a pair of columns, an open living and dining room area creates a
comfortable space for entertaining, with sliding glass doors guaranteeing a
bright, cheerful interior while providing easy access to outdoor living. The
L-shaped kitchen has an island work surface, a planning desk and an informal
eating space. Sleeping arrangements include the master suite with its tray
ceiling and sliding glass doors to the backyard.
Full Specs & Features
Dimension
Depth : 49'
Height : 24'
Width : 52' 8"
Height : 24'
Width : 52' 8"
Area
First Floor: 1699 sq/ft height 9'
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x6
Framing : Wood - 2x6
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Formal Dining Room
Formal Living Room / Parlor
Outdoor Spaces
Covered Front Porch
Rooms
Dining Room:
121 sq/ft width 12' 2" x depth 10'
Hall Bathroom:
86 sq/ft width 7' 8" x depth 11' 4"
Laundry Room:
14 sq/ft width 5' 7" x depth 2' 8"
Living Room:
265 sq/ft width 17' 4" x depth 15' 4"
Master Bathroom:
73 sq/ft width 7' 7" x depth 9' 8"
Master Bedroom:
182 sq/ft width 14' x depth 13'
Master Closet:
45 sq/ft width 5' x depth 9'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
