3rd BR Closet:
13 sq/ft width 6' 8" x depth 2'
121 sq/ft width 11' x depth 11'
110 sq/ft width 10' x depth 11'
Bedroom 4 Closet:
12 sq/ft width 6' x depth 2'
Bonus Room - Finished:
143 sq/ft width 11' x depth 13'
110 sq/ft width 11' x depth 10'
130 sq/ft width 10' x depth 13'
506 sq/ft width 23' x depth 22'
288 sq/ft width 18' x depth 16'
width 3' 6" x depth 0"
64 sq/ft width 10' 8" x depth 6'
6 sq/ft width 2' x depth 3'
120 sq/ft width 10' x depth 12'
35 sq/ft width 5' 4" x depth 6' 8"
106 sq/ft width 8' x depth 13' 4"
208 sq/ft width 16' x depth 13'
43 sq/ft width 6' 2" x depth 7'
Porch - Rear:
100 sq/ft width 10' x depth 10'
28 sq/ft width 4' 8" x depth 6'
All plans are drawn at ¼” scale or larger and include :
|5 Copy Set :
|5 printed plan sets mailed to you.|
|8 Copy Set :
|8 printed plan sets mailed to you.|
|Reproducible Set :
|For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.|
|CAD Set :
|For use by design professionals to make substantial changes to your house plan and inexpensive local printing.|
|Single Set :
|One printed set for bidding purposes only. Not a legal building set for construction.|
|Ideal for level lot, lower level of home partially or fully underground.|
|Additional Construction Sets :
|Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).|
|Audio Video Design :
|Receive an overlay sheet with suggested placement of audio and video components.|
|Construction Guide :
|Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.|
|Lighting Design :
|Receive an overlay sheet with suggested placement of lighting fixtures.|
|Mirror Reversed Sets :
|A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.|
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
