PLAN 120-149
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Dimension
Depth : 45' 6"
Height : 18'
Width : 52' 11"
Height : 18'
Width : 52' 11"
Area
First Floor: 1485 sq/ft height 9'
Second Floor: 373 sq/ft
Second Floor: 373 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 12:12
Roof Framing : Conventional
Roof Type : Shingle
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : 2"x4"
Framing : 2"x4"
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Kitchen Island
Additional Room Features
Family Room Keeping Room
Garage Features
Detached Garage
Rear Garage
Rear Garage
Lot Characteristics
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Covered Rear Porch
Rooms
3rd BR Closet:
13 sq/ft width 6' 6" x depth 2'
Basement Foundation:
2090 sq/ft width 52' 11" x depth 39' 6"
Bathroom 2:
50 sq/ft width 10' x depth 5'
Bedroom 2:
104 sq/ft width 10' x depth 10' 5"
Bedroom 2 Closet:
13 sq/ft width 6' 6" x depth 2'
Bedroom 3:
104 sq/ft width 10' x depth 10' 5"
Bedroom 3 Closet:
13 sq/ft width 6' 6" x depth 2'
Breakfast Room:
120 sq/ft width 10' x depth 12'
Crawlspace Foundation:
2090 sq/ft width 52' 11" x depth 39' 6"
Dining Room:
157 sq/ft width 12' 5" x depth 12' 8"
Foyer:
67 sq/ft width 6' 3" x depth 10' 9"
Garage:
458 sq/ft width 21' 5" x depth 21' 5"
Gathering Room:
306 sq/ft width 18' x depth 17'
Hall:
28 sq/ft width 9' 5" x depth 3'
Kitchen:
165 sq/ft width 11' 9" x depth 14' 1"
Master Bathroom:
160 sq/ft width 12' 8" x depth 12' 8"
Master Bedroom:
213 sq/ft width 15' 2" x depth 14' 1"
Master Closet:
35 sq/ft width 7' 2" x depth 5'
Porch - Front:
247 sq/ft width 41' 3" x depth 6'
Porch - Left:
24 sq/ft width 3' 6" x depth 7'
Porch - Rear:
91 sq/ft width 13' x depth 7'
Slab Foundation:
2090 sq/ft width 52' 11" x depth 39' 6"
Utility Room:
61 sq/ft width 9' 2" x depth 6' 8"
What's Included In This Plan Set
- Designer offers a 2nd Build License for $395 with a PDF purchase as well as an Unlimited License for $395 with the purchase of a CAD.
- Floor Plans – ¼”=1’-0” scale floor plan indicating location of frame and masonry walls, support members, doors, windows, plumbing fixtures, cabinets, shelving, ceiling conditions and notes deemed relevant to this plan.
- Exterior Elevations – All elevations at ¼” = 1’-0” scale in most cases. Some older designs may contain 1/8” scale side and rear elevations. Drawing will indicate overall configuration of home at each side view and make note of plate heights, roof overhangs, window header heights, roof pitches, materials used and extent to which they are used and enlargement of any details we feel necessary to explain the construction.
- Building Sections – ¼” = 1’-0” building sections are included when there is no other reasonable way to indicate the volumetric/height conditions in the home. Most of this information can usually be determined from the exterior elevations.
- Cabinet Elevations – 3/8” = 1’-0” scale elevations indicating configuration of cabinets, heights, widths, type of components used, cabinet material and finish, counter surfaces, appliances.
- Framing Plans – ¼” – 1’-0” scale framing plans indicating size and spacing of members as well as bracing and blocking required for structural purposes. Local codes will most likely need to be consulted.
- Foundation Plans – ¼” = 1’-0” scale foundation plans indicating location of structural walls, grade beams, reinforcing steel and structural columns. Consulting a local engineer is advisable as well as is analysis of soil conditions on site.
- Electrical Plans – ¼” = 1’-0” scale schematic plans indicating location and types of electrical fixtures, switches, outlets, and how they are to be switched.
Questions? Call 1-888-447-1946
Plan Set
| PDF Set : $895.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| Reproducible Set : $895.00 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
| 5 Copy Set : $1045.00 |
5 printed plan sets mailed to you. |
| 5 Copy and PDF Set : $1145.00 |
5 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| CAD Set : $1695.00 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
| Crawlspace: $0.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
| Basement: $395.00 |
Ideal for level lot, lower level of home partially or fully underground. |
Framing
| Wood 2x4: $0.00 |
Wood 2x4 |
| Wood 2x6: $245.00 |
Wood 2x6 |
Additional Options
| Right-Reading Reverse : $195.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Additional Construction Sets : $50.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Additional Use License : $395.00 |
Additional Use License. |
| Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Unlimited Use License : $395.00 |
Unlimited Use License. |
| 3 Car Garage : $195.00 |
Adds an additional garage bay |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
Unless you buy an “unlimited” plan
set or a multi-use license you may only build one home from a set of plans. Please
call to verify if you intend to build more than once. Plan licenses are
non-transferable and cannot be resold.
