PLAN 90-103
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 40'
Height : 20'
Width : 68'
Area
First Floor: 1871 sq/ft
Ceiling
Main Ceiling : 8'
Roof
Primary Pitch : 7:12
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : 2"x6"
Bedroom Features
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Additional Room Features
Family Room Keeping Room
Rooms
3rd BR Closet:
13 sq/ft width 2' x depth 6' 6"
Bedroom 3:
117 sq/ft width 11' 10" x depth 9' 11"
Bedroom 4:
118 sq/ft width 11' 10" x depth 10'
Bedroom 4 Closet:
17 sq/ft width 2' x depth 8' 6"
Breakfast Room:
126 sq/ft width 10' x depth 12' 8"
Dining Room:
126 sq/ft width 10' x depth 12' 8"
Foyer:
84 sq/ft width 12' x depth 7'
Garage:
425 sq/ft width 19' 6" x depth 21' 10"
Gathering Room:
234 sq/ft width 13' x depth 18'
Hall:
width 3' 1" x depth 0"
Hall Bathroom:
41 sq/ft width 5' x depth 8' 4"
Hall Closet:
11 sq/ft width 2' 4" x depth 4' 10"
Kitchen:
112 sq/ft width 11' 10" x depth 9' 6"
Laundry Room:
63 sq/ft width 5' 6" x depth 11' 6"
Living Room:
150 sq/ft width 12' 6" x depth 12'
Master Bathroom:
55 sq/ft width 5' 4" x depth 10' 6"
Master Bedroom:
163 sq/ft width 14' x depth 11' 8"
Master Closet:
40 sq/ft width 7' 8" x depth 5' 4"
