PLAN 434-3
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 86'
Height : 21'
Width : 40'
Area
Decks : 64 sq/ft
Garage : 541 sq/ft
Main Floor : 1915 sq/ft
Porch : 192 sq/ft
Ceiling
Ceiling Details : Garage ceiling height is 9'-6" min.
Garage Ceiling : 9'
Main Ceiling : 9'
Roof
Primary Pitch : 8:12
Roof Framing : Trusses
Roof Load : Live 25lbs psf.
Roof Type : Composition
Secondary Pitch : 6:12
Exterior Wall Framing
Exterior Wall Finish : Lap Siding
Framing : 2"x6"
Insulation : Batt
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Additional Room Features
Great Room Living Room
Main Floor Laundry
Mud Room
Garage Features
Rear Entry Garage
Rear Garage
Lot Characteristics
Suited For Corner Lot
Suited For Narrow Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Energy Efficient Features
Green Specifications
What's Included In This Plan Set
- Cover Sheet
- General Notes
- Energy Notes
- Energy Detail; drawings
- Foundation Plan: 1/4" - 1'0"
- Main and Upper Level Floor Framing: 1/4" - 1'0"
- Main and Upper Level Floor Plan: 1/4" - 1'0"
- Roof Framing Plan: 1/4" - 1'0"
- Building Sections: 1/4" - 1' 0"
- Typical Wall Section: 1/2" - 1' 0"
- Exterior Elevations
- Exterior Details
- Electrical switch and outlet plan: 1/4" - 1'0"
Plan Set
$760.00
$880.00
$1000.00
$1200.00
$2160.00
$600.00
Foundation
$0.00
$80.00
Framing
$0.00
Additional Options
$360.00
$40.00
$120.00
$236.00
$31.20
$120.00
$80.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
