PLAN 17-2412
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 81' 4"
Height : 26' 8"
Width : 39'
Area
Bonus: 810 sq/ft height 9'
First Floor: 1927 sq/ft height 10'
Garage: 448 sq/ft
Porch: 275 sq/ft
Ceiling
Bonus Ceiling : 9'
Main Ceiling : 10'
Roof
Primary Pitch : 0:0
Roof Framing : stick
Roof Load : 45
Roof Type : shingle
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : 2"x4"
Insulation : R13
Bedroom Features
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Additional Room Features
Den Office Study Computer
Great Room Living Room
Play Flex Room
Storage Area
Unfinished Future Space
Garage Features
Rear Entry Garage
Rear Garage
Outdoor Spaces
Covered Front Porch
Grill Deck Sundeck
Rooms
Bedroom 2:
147 sq/ft width 12' 4" x depth 12'
Bedroom 3:
176 sq/ft width 12' 4" x depth 14' 4"
Breakfast Room:
115 sq/ft width 7' 8" x depth 15'
Covered Porch:
144 sq/ft width 18' x depth 8'
Dining Room:
132 sq/ft width 11' x depth 12'
Foyer:
72 sq/ft width 6' x depth 12'
Garage:
400 sq/ft width 20' x depth 20'
Great Room:
306 sq/ft width 17' x depth 18'
Grilling Porch:
128 sq/ft width 8' x depth 16'
Kitchen:
120 sq/ft width 10' x depth 12'
Laundry Room:
42 sq/ft width 7' x depth 6'
Master Bathroom:
184 sq/ft width 12' 4" x depth 15'
Master Suite:
234 sq/ft width 12' 4" x depth 19'
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost. (Walk out is not shown on elevations unless finished walk out.)
- CAD Unlimited Build comes with a free PDF.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. ** (cut throughs where applicable)
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
Plan Set
$1100.00
$1200.00
$1450.00
$1800.00
$2200.00
$2200.00
Foundation
$0.00
$0.00
$299.00
$299.00
Framing
$0.00
$299.00
Additional Options
$299.00
$80.00
$100.00
$295.00
$39.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
