PLAN 70-829
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 55' 4"
Height : 21'
Width : 66'
Area
First Floor: 1934 sq/ft
Garage: 975 sq/ft
Porch: 46 sq/ft
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Roof Type : Shingle
Secondary Pitch : 6:12
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : 2"x6"
Bedroom Features
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Great Room Living Room
Storage Area
Garage Features
Oversized Garage
Lot Characteristics
Suited For View Lot
Rooms
Bathroom 2:
24 sq/ft width 3' 6" x depth 7'
Bathroom 3:
45 sq/ft width 9' x depth 5'
Bedroom 2:
143 sq/ft width 11' 4" x depth 12' 8"
Bedroom 2 Closet:
22 sq/ft width 5' x depth 4' 6"
Bedroom 3:
147 sq/ft width 13' x depth 11' 4"
Bedroom 3 Closet:
25 sq/ft width 5' x depth 5' 2"
Dining Room:
108 sq/ft width 12' x depth 9'
Front Entry:
75 sq/ft width 6' 8" x depth 11' 4"
Garage:
808 sq/ft width 33' x depth 24' 6"
Garage Storage:
143 sq/ft width 11' 4" x depth 12' 8"
Gathering Room:
306 sq/ft width 17' 4" x depth 17' 8"
Hall:
55 sq/ft width 3' 8" x depth 15' 2"
Kitchen:
229 sq/ft width 17' 8" x depth 13'
Laundry Room:
38 sq/ft width 5' 6" x depth 7'
Master Bathroom:
121 sq/ft width 11' 4" x depth 10' 9"
Master Bedroom:
209 sq/ft width 15' 6" x depth 13' 6"
Master Closet:
13 sq/ft width 2' x depth 6' 8"
Master Closet Two:
37 sq/ft width 5' 8" x depth 6' 8"
Porch - Front:
46 sq/ft width 6' x depth 7' 8"
Porch - Right:
51 sq/ft width 5' 8" x depth 9'
