Full Specs & Features
Depth : 42' 4"
Height : 27'
Width : 81' 10"
Basement Unfinished: 1966 sq/ft
First Floor: 1958 sq/ft height 8'
Garage: 448 sq/ft
Primary Pitch : 6:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Formal Living Room / Parlor
Main Floor Master Bedroom
Additional Room Features
Family Room Keeping Room
Covered Front Porch
width 11' x depth 12'
width 11' 4" x depth 12'
width 11' x depth 11'
width 9' x depth 8'
width 10' x depth 12'
width 20' x depth 20' 6"
width 10' 6" x depth 9'
width 16' x depth 12'
width 16' x depth 13' 6"
63 sq/ft width 6' 6" x depth 0"
width 13' 4" x depth 6'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
