Full Specs & Features
Depth : 56' 10"
Height : 18' 6"
Width : 62'
First Floor: 2027 sq/ft height 9'
Primary Pitch : 6:12
Roof Framing : Trusses
Roof Type : Concrete Tile
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : 2"x4"
Main Floor Bedrooms
Main Floor Master Bedroom
Walk In Closet
Additional Room Features
Den Office Study Computer
Great Room Living Room
Suited For Corner Lot
Covered Front Porch
Covered Rear Porch
132 sq/ft width 11' x depth 12'
136 sq/ft width 10' x depth 13' 8"
48 sq/ft width 12' x depth 4'
110 sq/ft width 11' x depth 10'
810 sq/ft width 30' x depth 27'
338 sq/ft width 16' 6" x depth 20' 6"
144 sq/ft width 12' x depth 12'
117 sq/ft width 10' 8" x depth 11'
224 sq/ft width 14' x depth 16'
Master Walk-In Closet:
60 sq/ft width 5' x depth 12'
149 sq/ft width 11' 6" x depth 13'
What's Included In This Plan Set
Please note: This designer has the following the zip code restrictions: 30041, 30501, 30504, 30506, 30542, and 30566.
Plans include detailed front, sides, and rear exterior drawings. These drawings give notes on all exterior materials and finishes (siding, brick, stone, etc).
Dimensioned exterior and interior wall framing along with labeled windows/doors sizes in each room of home. Wall heights are indicated for each level. Room sizes are indicated and any beams, posts and structural bearing points are called out.
Foundation Plan and Footings
The foundation page shows concrete walls, footings, pads, posts, beams, bearing walls, and any retaining wall info (schematic only). Typical wall section details are shown for various footings. On plans drawn as walk out basements, if you choose the optional Slab foundation, the slab foundation will not be reflected in the exterior elevations.
Roof plan showing all hips, ridges, and valleys along with slope directions are indicated. Structural members are sized and called out if applicable.
Building Sections & Details
Building sections show changes in floor, ceiling, or roof height, and the relationship of one level to another. Some plans will have additional cross–section and details as needed for displaying any special framing details applicable to the design.
Notes and Details Page(s)
The floorplans include an electrical legend, electrical fittings, lights, and outlets are shown. Plans meet the requirements of the ‘International Residential Code’. Compliance with further standards may need to be incorporated into your plan set, depending the requirements of your local/state building department — these typically are done locally.
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
