PLAN 17-2683
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Dimension
Depth : 77' 4"
Height : 29'
Width : 35' 10"
Height : 29'
Width : 35' 10"
Area
First Floor: 1393 sq/ft
Porch: 80 sq/ft
Second Floor: 742 sq/ft
Storage: 427 sq/ft
Porch: 80 sq/ft
Second Floor: 742 sq/ft
Storage: 427 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 12:12
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Framing : Wood - 2x4
Bedroom Features
Fireplace
Main Floor Master Bedroom
Main Floor Master Bedroom
Additional Room Features
Great Room Living Room
Loft
Loft
Outdoor Spaces
Balcony
Rooms
Bathroom 2:
78 sq/ft width 15' 8" x depth 5'
Bedroom 2:
151 sq/ft width 14' 6" x depth 10' 5"
Bedroom 3:
135 sq/ft width 13' x depth 10' 5"
Breakfast Room:
82 sq/ft width 8' x depth 10' 3"
Covered Porch:
40 sq/ft width 8' x depth 5'
Dining Room:
159 sq/ft width 13' 4" x depth 12'
Foyer:
49 sq/ft width 8' x depth 6' 2"
Garage:
400 sq/ft width 20' x depth 20'
Great Room:
279 sq/ft width 13' 4" x depth 21'
Kitchen:
116 sq/ft width 8' x depth 14' 7"
Loft:
124 sq/ft width 13' 4" x depth 9' 4"
Master Bathroom:
119 sq/ft width 8' 6" x depth 14'
Master Bedroom:
184 sq/ft width 12' 4" x depth 15'
Study:
172 sq/ft width 12' 4" x depth 14'
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. **
- Kitchen and bath elevations: The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
