PLAN 17-3363
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Dimension
Depth : 85' 8"
Height : 20' 8"
Width : 68' 4"
Height : 20' 8"
Width : 68' 4"
Area
First Floor: 2247 sq/ft height 8'
Garage: 608 sq/ft height 8'
Porch: 671 sq/ft
Garage: 608 sq/ft height 8'
Porch: 671 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 8:12
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x4
Framing : Wood - 2x4
Bedroom Features
Formal Living Room / Parlor
Walk In Closet
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Kitchen Island
Additional Room Features
Media Room
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Deck
Covered Rear Porch
Deck
Rooms
Bedroom 2:
148 sq/ft width 12' 2" x depth 12' 2"
Bedroom 3:
148 sq/ft width 12' 2" x depth 12' 2"
Dining Room:
281 sq/ft width 13' x depth 21' 8"
Garage:
576 sq/ft width 24' x depth 24'
Grilling Porch:
216 sq/ft width 18' x depth 12'
Kitchen:
297 sq/ft width 14' 5" x depth 20' 8"
Laundry Room:
91 sq/ft width 13' 8" x depth 6' 8"
Living Room:
343 sq/ft width 24' 10" x depth 13' 10"
Master Bathroom:
186 sq/ft width 13' 8" x depth 13' 8"
Master Suite:
189 sq/ft width 13' 8" x depth 13' 10"
Media Room:
320 sq/ft width 16' x depth 20'
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. **
- Kitchen and bath elevations: The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
