PLAN 120-194

Key Specs


2352
sq ft

3
Beds

3
Baths

1
Floors

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.

Plan Description


Interesting angles are created in this Hill Country house plan, with the bedrooms jutting out to the sides. A grand open floor plan makes the home feel larger by opening up the sight-lines. Vaulted and tray ceilings generate great visual appeal. From the kitchen island you can see everything that's going on in the family room, nook and outdoor lanai with its outdoor fireplace and grilling station. The beautiful master suite gets a private terrace, double tray ceiling, a well laid-out master bathroom and a big walk-in closet. Both of the other family bedrooms are on the opposite side of the home. Climb the stairs to the optional bonus room on the second floor, that adds 352 square feet of living space if finished.

Full Specs & Features


Dimension
Depth : 57' 6"
Height : 21'
Width : 90' 5"
Area
Bonus : 352 sq/ft
Garage : 508 sq/ft
Lower Floor : 2352 sq/ft
Main Floor : 2352 sq/ft
Porch : 560 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
