PLAN 120-119
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Dimension
Depth : 59' 6"
Height : 33'
Width : 61' 3"
Height : 33'
Width : 61' 3"
Area
Bonus: 361 sq/ft
First Floor: 1848 sq/ft height 9'
Second Floor: 537 sq/ft
First Floor: 1848 sq/ft height 9'
Second Floor: 537 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 12:12
Roof Framing : Conventional
Roof Type : Shingle
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : 2"x4"
Framing : 2"x4"
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Walk In Pantry Cabinet Pantry
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Family Room Keeping Room
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Covered Rear Porch
Rooms
3rd BR Closet:
16 sq/ft width 2' x depth 8' 4"
Basement Foundation:
2664 sq/ft width 61' 3" x depth 43' 6"
Bathroom 2:
59 sq/ft width 5' x depth 11' 10"
Bedroom 2:
143 sq/ft width 11' x depth 13' 1"
Bedroom 2 Closet:
14 sq/ft width 7' 4" x depth 2'
Bedroom 3:
138 sq/ft width 11' 8" x depth 11' 10"
Bedroom 3 Closet:
14 sq/ft width 7' 4" x depth 2'
Breakfast Room:
113 sq/ft width 9' 11" x depth 11' 5"
Crawlspace Foundation:
2664 sq/ft width 61' 3" x depth 43' 6"
Dining Room:
160 sq/ft width 14' 3" x depth 11' 3"
Foyer:
148 sq/ft width 7' 10" x depth 19'
Garage:
464 sq/ft width 21' 5" x depth 21' 8"
Gathering Room:
361 sq/ft width 19' x depth 19'
Hall:
63 sq/ft width 19' 6" x depth 3' 3"
Kitchen:
247 sq/ft width 16' 1" x depth 15' 5"
Master Bathroom:
129 sq/ft width 13' 4" x depth 9' 9"
Master Bedroom:
360 sq/ft width 18' x depth 20'
Master Closet:
46 sq/ft width 7' 7" x depth 6' 1"
Porch - Front:
436 sq/ft width 54' 6" x depth 8'
Porch - Rear:
349 sq/ft width 43' 8" x depth 8'
Powder Room:
28 sq/ft width 5' 1" x depth 5' 7"
Utility Room:
48 sq/ft width 8' x depth 6' 1"
Walk-In Closet:
14 sq/ft width 5' 3" x depth 2' 9"
What's Included In This Plan Set
- Designer offers a 2nd Build License for $395 with a PDF purchase as well as an Unlimited License for $395 with the purchase of a CAD.
- Floor Plans – ¼”=1’-0” scale floor plan indicating location of frame and masonry walls, support members, doors, windows, plumbing fixtures, cabinets, shelving, ceiling conditions and notes deemed relevant to this plan.
- Exterior Elevations – All elevations at ¼” = 1’-0” scale in most cases. Some older designs may contain 1/8” scale side and rear elevations. Drawing will indicate overall configuration of home at each side view and make note of plate heights, roof overhangs, window header heights, roof pitches, materials used and extent to which they are used and enlargement of any details we feel necessary to explain the construction.
- Building Sections – ¼” = 1’-0” building sections are included when there is no other reasonable way to indicate the volumetric/height conditions in the home. Most of this information can usually be determined from the exterior elevations.
- Cabinet Elevations – 3/8” = 1’-0” scale elevations indicating configuration of cabinets, heights, widths, type of components used, cabinet material and finish, counter surfaces, appliances.
- Framing Plans – ¼” – 1’-0” scale framing plans indicating size and spacing of members as well as bracing and blocking required for structural purposes. Local codes will most likely need to be consulted.
- Foundation Plans – ¼” = 1’-0” scale foundation plans indicating location of structural walls, grade beams, reinforcing steel and structural columns. Consulting a local engineer is advisable as well as is analysis of soil conditions on site.
- Electrical Plans – ¼” = 1’-0” scale schematic plans indicating location and types of electrical fixtures, switches, outlets, and how they are to be switched.
