Key Specs
2420
sq ft
3
Beds
2.5
Baths
2
Floors
2
Garages
Phone: 1-888-447-1946
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 72-994
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 34' 8"
Height : 30'
Width : 52' 4"
Area
First Floor: 1216 sq/ft height 8'
Second Floor: 1204 sq/ft
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : Wood - 2x6
Bedroom Features
Fireplace
Formal Dining Room
Formal Living Room / Parlor
Split Bedrooms
Kitchen Features
Breakfast Nook
Kitchen Island
Additional Room Features
Family Room Keeping Room
Loft
Main Floor Laundry
Open Floor Plan
Outdoor Spaces
Balcony
Courtyard
Covered Front Porch
Rooms
3rd BR Closet:
31 sq/ft width 6' x depth 5' 2"
Attic:
171 sq/ft width 19' x depth 9'
Bedroom 2:
136 sq/ft width 11' 8" x depth 11' 8"
Bedroom 2 Closet:
29 sq/ft width 2' 6" x depth 11' 8"
Bedroom 3:
128 sq/ft width 11' 4" x depth 11' 4"
Bedroom 3 Closet:
29 sq/ft width 2' 6" x depth 11' 8"
Breakfast Room:
118 sq/ft width 11' 4" x depth 10' 6"
Dining Room:
116 sq/ft width 11' 8" x depth 10'
Foyer:
49 sq/ft width 5' 6" x depth 9'
Gathering Room:
153 sq/ft width 13' 4" x depth 11' 6"
Hall Bathroom:
49 sq/ft width 7' x depth 7'
Kitchen:
135 sq/ft width 12' 4" x depth 11'
Laundry Room:
40 sq/ft width 8' x depth 5'
Living Room:
217 sq/ft width 13' 4" x depth 16' 4"
Master Bathroom:
156 sq/ft width 12' x depth 13'
Master Bedroom:
201 sq/ft width 12' 4" x depth 16' 4"
Powder Room:
35 sq/ft width 5' x depth 7'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$1191.96
$1330.56
$1469.16
Foundation
$0.00
$275.00
$275.00
$275.00
Framing
$0.00
Additional Options
$195.00
$60.00
$495.00
$150.00
$295.00
$39.00
$150.00
$85.00
$0.00
$995.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
