Depth : 76' 11"
Height : 26' 6"
Width : 69' 10"
First Floor: 2464 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof Framing : Conventional
Roof Type : Asphalt
Exterior Wall Framing
Exterior Wall Finish : Brick/Stucco
Framing : Wood - 2x4
Formal Dining Room
Formal Living Room / Parlor
Walk In Closet
Additional Room Features
Vaulted / Cathedral Ceilings
Covered Front Porch
Covered Rear Porch
