PLAN 430-35
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Floor Plan - Main Floor
Floor Plan - Other Floor
Floor Plan - Other Floor
Full Specs & Features
Dimension
Depth : 51'
Height : 25' 10"
Width : 80' 8"
Area
Bonus: 346 sq/ft
First Floor: 2500 sq/ft height 9'
Garage: 542 sq/ft
Storage: 98 sq/ft
Ceiling
Bonus Ceiling : 8'
Main Ceiling : 9'
Roof
Primary Pitch : 8:12
Roof Framing : Conventional
Roof Type : Shingle
Secondary Pitch : 12:12
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : 2"x4"
Bedroom Features
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Play Flex Room
Storage Area
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
More
Jack & Jill Bath
Rooms
Bedroom 2:
width 12' 8" x depth 11' 10"
Bedroom 3:
width 12' 6" x depth 11'
Bedroom 4/ Study:
width 11' 6" x depth 12' 6"
Breakfast Nook:
width 11' 6" x depth 11'
Covered Front Porch:
186 sq/ft width 31' x depth 6'
Covered Rear Porch:
129 sq/ft width 18' 6" x depth 7' 6"
Dining Room:
width 11' 2" x depth 12' 6"
Foyer:
width 6' 8" x depth 12' 6"
Garage:
542 sq/ft width 21' 10" x depth 23' 6"
Great Room:
width 18' 6" x depth 19' 2"
Kitchen:
width 11' 6" x depth 15' 8"
Master Bedroom:
width 15' 6" x depth 15' 4"
Optional Bonus Room:
346 sq/ft width 11' 6" x depth 20' 2"
Powder room:
width 5' 4" x depth 5' 4"
Utility Room:
width 9' 10" x depth 7' 10"
What's Included In This Plan Set
Purchasing a CAD set gives you an unlimited build license.
- Cover Sheet – May include index, front view of home, definitions, etc.
- Foundation Plan – Typically includes dimensioned foundation plan with footing details.
- Dimensioned Floor Plan – Electrical may be shown.
- Exterior Views – Four exterior views of the residence with other miscellaneous details.
- Roof Plan – Birds eye view showing all ridges, valleys and other necessary information.
- Electrical Plan – Displays all lighting fixtures, outlets and other necessary electrical items. These items may be shown on the Dimensioned Floor Plan. Switches and arcs are not shown and should be located by owner/contractor at site.
- Wall Section(s) – Detail of wall materials and assembly.
- Building Section(s) – Section through home displaying necessary information about framing and other miscellaneous data.
- Cabinet Elevations – Displays interior kitchen cabinet views.
*Material List Note: When a material list is ordered, a list of the materials needed to build this plan will be sent. Please note that the materials list will conform to the standard plan (slab or crawlspace only). Additional options such as a Basement or 2x6 Wall conversion will not be reflected in the material list.
________________________
Note about 2x6 Wall Option: If choosing the 2x6 wall option, the added stud depth will be applied towards the interior of the walls.
Plan Set
$1228.25
$1440.75
$1823.25
$2035.75
$2163.25
Foundation
$0.00
$85.00
$335.75
Framing
$0.00
$276.25
Additional Options
$191.25
$85.00
$420.75
$140.25
$33.15
$140.25
$212.50
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
