PLAN 14-209
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 54'
Height : 28'
Width : 84'
Area
First Floor: 1577 sq/ft height 9'
Second Floor: 981 sq/ft
Roof
Primary Pitch : 5:12
Roof Framing : Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding
Framing : Wood - 2x4
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Additional Room Features
Great Room Living Room
Storage Area
Garage Features
Carport Porte Cochere
Outdoor Spaces
Breezeway
Wrap Around Porch
Rooms
3rd BR Closet:
36 sq/ft width 6' x depth 6'
Bedroom 2:
238 sq/ft width 14' x depth 17'
Bedroom 2 Closet:
35 sq/ft width 7' x depth 5'
Bedroom 3:
182 sq/ft width 14' x depth 13'
Bedroom 3 Closet:
35 sq/ft width 7' x depth 5'
Bedroom 4:
182 sq/ft width 14' x depth 13'
Bedroom 4 Closet:
12 sq/ft width 6' x depth 2'
Bedroom 5:
221 sq/ft width 17' x depth 13'
Breakfast Room:
121 sq/ft width 11' x depth 11'
Dining Room:
143 sq/ft width 13' x depth 11'
Foyer:
35 sq/ft width 7' x depth 5'
Gathering Room:
391 sq/ft width 17' x depth 23'
Kitchen:
176 sq/ft width 16' x depth 11'
Master Bathroom:
252 sq/ft width 14' x depth 18'
Master Bedroom:
252 sq/ft width 14' x depth 18'
Master Closet:
88 sq/ft width 8' x depth 11'
Porch - Front:
300 sq/ft width 50' x depth 6'
Porch - Left:
237 sq/ft width 36' 6" x depth 6' 6"
Porch - Rear:
108 sq/ft width 18' x depth 6'
Porch - Right:
210 sq/ft width 35' x depth 6'
Powder Room:
32 sq/ft width 4' x depth 8'
Utility Room:
120 sq/ft width 8' x depth 15'
Walk-In Closet:
6 sq/ft width 3' x depth 2'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
- Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
Plan Set
$573.75
$658.75
$658.75
$467.50
Foundation
$0.00
$0.00
Additional Options
$42.50
$85.00
$33.15
$85.00
$42.50
$0.00
* Alternate Foundations may take time to prepare.
