Full Specs & Features
Depth : 78' 6"
Height : 24' 8"
Width : 68' 8"
First Floor: 2280 sq/ft height 9'
Second Floor: 329 sq/ft height 8'
Primary Pitch : 8:12
Roof Framing : Conventional
Roof Type : Tile
Exterior Wall Framing
Framing : Wood - 2x4
Formal Dining Room
Main Floor Master Bedroom
Walk In Closet
Kitchenette Wet Bar
Additional Room Features
Great Room Living Room
Main Floor Laundry
Covered Rear Porch
144 sq/ft width 10' 8" x depth 13' 6"
134 sq/ft width 11' 2" x depth 12'
132 sq/ft width 11' x depth 12'
132 sq/ft width 12' x depth 11'
80 sq/ft width 10' x depth 8'
155 sq/ft width 14' 2" x depth 11'
240 sq/ft width 20' x depth 12'
814 sq/ft width 22' x depth 37'
370 sq/ft width 20' x depth 18' 6"
174 sq/ft width 14' 6" x depth 12'
156 sq/ft width 13' x depth 12'
115 sq/ft width 8' 2" x depth 14' 2"
Porch - Screened:
155 sq/ft width 15' 6" x depth 10'
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost. (Walk out is not shown on elevations unless finished walk out.)
- CAD Unlimited Build comes with a free PDF.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. ** (cut throughs where applicable)
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
