PLAN 21-363
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Floor Plan - Main Floor
Floor Plan - Other Floor
Full Specs & Features
Dimension
Depth : 67' 10"
Height : 26'
Width : 84'
Area
Bonus: 443 sq/ft height 8'
First Floor: 2724 sq/ft height 9'
Ceiling
Main Ceiling : 9'
Roof
Primary Pitch : 8:12
Roof Framing : stick
Roof Load : 40
Roof Type : hip
Secondary Pitch : 14:12
Exterior Wall Framing
Exterior Wall Finish : brick/siding
Framing : 2 x 4
Bedroom Features
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Play Flex Room
Storage Area
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Rooms
Bath 2:
width 12' 2" x depth 5' 8"
Bath 3:
width 9' 10" x depth 5' 6"
Bedroom 2:
width 11' 6" x depth 12'
Bedroom 3:
width 12' 2" x depth 11' 6"
Bedroom 4:
width 14' x depth 11' 6"
Bonus:
443 sq/ft width 18' 8" x depth 18'
Breakfast:
width 13' 8" x depth 15' 2"
Dining:
width 11' 6" x depth 12'
Entry:
width 8' 2" x depth 6' 4"
Foyer:
width 6' x depth 12'
Garage:
width 23' 8" x depth 35'
Great Room:
width 20' x depth 17' 6"
Kitchen:
width 16' x depth 13' 2"
Laundry:
width 14' 4" x depth 8'
Master Bath:
width 17' 4" x depth 9' 2"
Master Bedroom:
width 14' 6" x depth 17' 6"
Master Closet:
width 10' 4" x depth 8'
Master Closet 2:
width 60' 8" x depth 8'
Porch Front:
width 35' x depth 6'
Porch Rear:
width 20' 8" x depth 10' 10"
What's Included In This Plan Set
- Cover Sheet: Color rendering or black and white image of the exterior
- Foundation Plan(s): Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
- Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
- Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
- Interior Elevations: Where applicable, each house plan set includes relevant interior elevations, including cabinets, cabinet details, columns and walls with unique conditions.
- Overhead Roof Plan(s): Overhead view of roof.
- Cross Section(s): A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
- Electrical Plan(s): Lighting, outlets, switches, detectors, etc.
- Kitchen Cabinet Elevation(s): Scaled drawings of interior cabinets.
- Construction Notes and Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
- Framing Detail(s): Ceiling joist size and spacing and layouts. If included, the framing layout is intended to be a suggested layout only. Design loads and weather conditions vary by region. As a result the size, spacing, and layout of all structural elements in this home design may need approval by a structural engineer or code official based on your specific site location.
- Wall Section(s): Exterior wall and roof sections and specialty details.
Plan Set
$1317.50
$1402.50
$1615.00
Foundation
$0.00
Additional Options
$127.50
$51.00
$140.25
$33.15
$140.25
$127.50
$42.50
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
