PLAN 1015-16

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.

Modify This Plan

Plan Description


This ranch style home, with all of the grandeur of a two-story, holds universal appeal to homebuyers. Your clients will be awed by the open feeling of this plan with its two-story foyer and spacious Kitchen that opens to the Family Room. Bedroom five holds a unique appeal to each client as it can be converted to fit their individual needs, whether that be a private office for those who need to work from home, a nursery with access to the Master Suite for those who are expanding their family, an exercise room or a cozy den, whatever your clients can envision.

Full Specs & Features


Dimension

Depth : 65' 8"

Height : 22' 4"

Width : 60'

Area

First Floor: 2789 sq/ft

Garage: 418 sq/ft

Storage: 33 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 6:12

Roof Framing : Truss

Roof Type : Shingle

Exterior Wall Framing

Exterior Wall Finish : Stucco

Framing : Block

Bedroom Features

Formal Dining Room

Formal Living Room / Parlor

Main Floor Master Bedroom

Walk In Closet

Kitchen Features

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Family Room Keeping Room

Main Floor Laundry

Outdoor Spaces

Covered Front Porch

Covered Rear Porch

Rooms

Bedroom 2:

128 sq/ft width 11' 8" x depth 11'

Bedroom 3:

128 sq/ft width 11' 8" x depth 11'

Bedroom 4:

128 sq/ft width 11' 8" x depth 11'

Bedroom 5:

176 sq/ft width 12' x depth 14' 8"

Bonus Room - Finished:

266 sq/ft width 14' x depth 19'

Breakfast Room:

60 sq/ft width 9' 6" x depth 6' 4"

Dining Room:

147 sq/ft width 11' 8" x depth 12' 8"

Family Room:

323 sq/ft width 18' 4" x depth 17' 8"

Garage:

383 sq/ft width 20' x depth 19' 2"

Kitchen:

200 sq/ft width 14' 8" x depth 13' 8"

Laundry Room:

41 sq/ft width 7' 2" x depth 5' 10"

Living Room:

134 sq/ft width 12' x depth 11' 2"

Master Bathroom:

122 sq/ft width 16' 8" x depth 7' 4"

Master Bedroom:

293 sq/ft width 13' 4" x depth 22'

Porch - Rear:

154 sq/ft width 14' x depth 11'

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
» See important information before purchasing.
Questions? Call 1-888-447-1946

Plan Set

PDF Set:
$1150.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
5 Copy Set:
$1350.00
5 printed plan sets mailed to you.
5 Copy and PDF Set:
$1500.00
5 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing.
CAD Single Build:
$2300.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
Study Set:
$700.00
One electronic set for bidding purposes only. Not a legal building set for construction.

Foundation

Slab:
$0.00
Ideal for level lot, single layer concrete poured directly on grade.

Framing

Block:
$0.00
Concrete Block Exterior Walls (Upper Levels may be wood-framed)

Additional Options

Additional Construction Sets:
$50.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design:
$100.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide:
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design:
$100.00
Receive an overlay sheet with suggested placement of lighting fixtures.
Mirror Reversed Sets:
$30.00
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.

* Alternate Foundations may take time to prepare.

** Options with a fee may take time to prepare. Please call to confirm.

Unless you buy an “unlimited” plan set or a multi-use license you may only build one home from a set of plans. Please call to verify if you intend to build more than once. Plan licenses are non-transferable and cannot be resold.
