PLAN 137-274
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 70' 11"
Height : 30' 7"
Width : 69'
Area
Bonus: 323 sq/ft
First Floor: 2818 sq/ft
Ceiling
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Roof Framing : stick
Roof Type : shingle
Exterior Wall Framing
Exterior Wall Finish : Ston/Horizontal Siding
Framing : 2 x 4
Bedroom Features
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Main Floor Laundry
Play Flex Room
Storage Area
Unfinished Future Space
Garage Features
Side Entry Garage
Outdoor Spaces
Covered Front Porch
More
Jack & Jill Bath
Rooms
Bedroom 2:
179 sq/ft width 13' 10" x depth 13'
Bedroom 3:
186 sq/ft width 12' x depth 15' 6"
Bedroom 4:
177 sq/ft width 13' x depth 13' 8"
Breakfast Area:
144 sq/ft width 12' x depth 12'
Dining Room:
180 sq/ft width 15' x depth 12'
Family Room:
436 sq/ft width 20' x depth 21' 10"
Garage:
483 sq/ft width 21' x depth 23'
Kitchen:
177 sq/ft width 14' x depth 12' 8"
Master Bedroom:
255 sq/ft width 17' x depth 15'
What's Included In This Plan Set
All plans are drawn at ¼” scale or larger and include :
Plans are typically drawn to ¼” scale and include:
- Foundation Plan(s): This page shows all necessary notations and dimensions including footings, support columns, walls, and excavated/unexcavated areas.
- Floor Plan(s): Detailed plans for each level showing room dimensions, wall partitions, windows and doors, fixture locations, and ceiling treatments.
- Exterior Elevations: Views of the home from all four sides showing exterior materials, roof slope, ridge heights, siding and trim notes.
- Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements.
- Overhead Roof Plan(s): A view of the home from above showing roof pitch, peaks, valleys, and other details.
- Cross Section(s): A slice of the home from roof to foundation, showing relationships between floors, roof, and foundation.
- Building Section(s): Shows the relationship between different levels, wall heights, and the overall building volume. May include details like foundation, framing, insulation, and finishes.
- Electrical Plan(s): Shows the location of lights, receptacles, switches, etc. Some plans that do not include an electrical plan may have it available for an additional fee.
- Construction Notes / Detail(s): Shows basic parts and assemblies recommended for the home so the builder can see how things come together.
- Rendering(s): Designer’s rendering of front elevation
Plan Set
$680.00
$765.00
$935.00
$935.00
$595.00
Foundation
$0.00
Additional Options
$46.75
$140.25
$250.75
$33.15
$140.25
$46.75
