PLAN 927-506
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.Plan Description
This home emphasizes easy living through a free-flowing floorplan and private spaces for retreat. Enter the combination kitchen breakfast nook through a wide foyer. Continue through the vaulted great room and retreat to the master suite; the bathroom's plans allow for customization. Upstairs are three additional bedrooms, all of which have walk-in closets, and two full baths - a perfect space for kids or grandkids to retreat to themselves.
Special offer for builders! Select a CAD, PDF, or Reproducible format, and you will receive an unlimited use license at no additional cost. Build as many times as you like with no re-use fees! This offer only applies to plans bearing this note. Unless explicitly noted, a purchased plan may only be built once. An unlimited use license is not transferable.
Special offer for builders! Select a CAD, PDF, or Reproducible format, and you will receive an unlimited use license at no additional cost. Build as many times as you like with no re-use fees! This offer only applies to plans bearing this note. Unless explicitly noted, a purchased plan may only be built once. An unlimited use license is not transferable.
Full Specs & Features
Dimension
Depth : 70'
Height : 31' 6"
Width : 40'
Height : 31' 6"
Width : 40'
Area
First Floor: 1809 sq/ft height 9'
Garage: 476 sq/ft height 9'
Second Floor: 1021 sq/ft height 9'
Garage: 476 sq/ft height 9'
Second Floor: 1021 sq/ft height 9'
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 9:12
Roof Framing : Conventional
Roof Type : Asphalt
Roof Framing : Conventional
Roof Type : Asphalt
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : Wood - 2x4
Framing : Wood - 2x4
Bedroom Features
Formal Dining Room
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Kitchen Island
Additional Room Features
Great Room Living Room
Loft
Vaulted / Cathedral Ceilings
Loft
Vaulted / Cathedral Ceilings
Outdoor Spaces
Balcony
Courtyard
Covered Front Porch
Courtyard
Covered Front Porch
Rooms
Bedroom 2:
162 sq/ft width 13' x depth 12' 6"
Bedroom 3:
151 sq/ft width 11' 8" x depth 13'
Bedroom 4:
147 sq/ft width 11' 4" x depth 13'
Breakfast:
120 sq/ft width 12' x depth 10'
Dining Room:
151 sq/ft width 11' 8" x depth 13'
Foyer:
46 sq/ft width 5' 6" x depth 8' 6"
Garage:
476 sq/ft width 21' 8" x depth 21' 7"
Grand Room:
62 sq/ft width 6' 4" x depth 9' 10"
Kitchen:
226 sq/ft width 17' 5" x depth 13'
Laundry Room:
62 sq/ft width 6' 4" x depth 9' 10"
Master Bathroom:
165 sq/ft width 11' x depth 15'
Master Bedroom:
221 sq/ft width 17' x depth 13'
Master Walk-In Closet:
75 sq/ft width 7' 6" x depth 10'
Study:
114 sq/ft width 10' 5" x depth 11'
What's Included In This Plan Set
- Purchasing a CAD set, PDF set, or Reproducible set, gives you an unlimited build license. All other plan sets, allow you to build the home one time.
- All plans include the front elevation at 1/4" or 3/16" and the sides and rear elevations at 1/8" scale. These elevations show and note the exterior finished materials of the house.
- Every plan is available with a walkout style basement (three masonry walls and one wood framed rear wall with windows and doors). The basement plans are a 1/4" or 3/16" scale layout of unfinished spaces showing only the necessary 2 x 6 wood framed load bearing walls. These plans are completed with dimensions, notes, and door/window sizes. Crawl space and/or slab on grade foundations are available for some plans. All foundation types are not available for all plans.
- Each plan consists of 1/4" or 3/16" scale floor layouts showing the location of 2x4 walls, doors, windows, plumbing fixtures, cabinetry, stairs and decorative ceilings. These plans are complete with dimensions, notes, door/window sizes and a schematic electrical layout.
- The building sections are drawings which take vertical cuts through the house and the stairs showing floor, ceiling and roof height information.
- The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer. Details are included for many interior and exterior conditions to provide more specific information for their construction.
- Each floor framing plan shows each floor joist indicating the size, spacing and length. All beams are labeled and sized. All of the joist are counted and coordinated with the material list. Each framing plan sheet includes any framing details that are needed (tray details, connection details, etc.). All of the framing is designed using conventional 2 X 10 floor joist or wood I-Joist, depending on the span conditions of each home plan. Framing plans are not available for all home plans.
- The ceiling joist framing plan shows each ceiling joist indicating the size,spacing and length. All beams are labeled and sized. All of the joist are counted and coordinated with the material list. Framing plans are not available for all home plans.
- The roof framing plan shows each rafter, valley, hip and ridge indicating the size, spacing and length. All beams are labeled and sized. All of the joist are counted and coordinated with the material list. Framing plans are not available for all home plans.
- Each plan order includes one set of typical detail sheets that show foundation details, typical wall sections and other framing details. Also included on the detail sheets are miscellaneous interior trim and fireplace details that can be used to customize the home.
