PLAN 17-2914
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Dimension
Depth : 86' 8"
Height : 24'
Width : 73' 2"
Height : 24'
Width : 73' 2"
Area
Bonus: 669 sq/ft height 8'
First Floor: 2560 sq/ft height 9'
Garage: 1189 sq/ft
Porch: 431 sq/ft
Second Floor: 286 sq/ft height 8'
First Floor: 2560 sq/ft height 9'
Garage: 1189 sq/ft
Porch: 431 sq/ft
Second Floor: 286 sq/ft height 8'
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 10:12
Roof Type : Shingle
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Main Floor Master Bedroom
Split Bedrooms
Formal Dining Room
Main Floor Master Bedroom
Split Bedrooms
Kitchen Features
Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Kitchen Island
Kitchenette Wet Bar
Additional Room Features
Den Office Study Computer
Great Room Living Room
Main Floor Laundry
Media Room
Storage Area
Unfinished Future Space
Workshop
Great Room Living Room
Main Floor Laundry
Media Room
Storage Area
Unfinished Future Space
Workshop
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Covered Rear Porch
More
Jack & Jill Bath
Rooms
Bathroom 2:
47 sq/ft width 9' 6" x depth 5'
Bathroom 3:
60 sq/ft width 7' 10" x depth 7' 8"
Bedroom 2:
142 sq/ft width 13' 4" x depth 10' 8"
Bedroom 3:
184 sq/ft width 13' 4" x depth 13' 10"
Bedroom 4:
166 sq/ft width 14' 6" x depth 11' 6"
Bonus Room - Finished:
192 sq/ft width 20' 7" x depth 9' 4"
Bonus Room - Unfinished:
627 sq/ft width 14' x depth 44' 10"
Breakfast Room:
119 sq/ft width 12' 4" x depth 9' 8"
Computer Room:
59 sq/ft width 7' x depth 8' 6"
Covered Porch:
85 sq/ft width 17' x depth 5'
Dining Room:
143 sq/ft width 12' 4" x depth 11' 8"
Foyer:
62 sq/ft width 11' 8" x depth 5' 4"
Garage:
602 sq/ft width 27' x depth 22' 4"
Garage Two:
540 sq/ft width 27' x depth 20'
Great Room:
311 sq/ft width 17' x depth 18' 4"
Grilling Porch:
360 sq/ft width 30' x depth 12'
Kitchen:
147 sq/ft width 12' 4" x depth 12'
Laundry Room:
77 sq/ft width 9' 6" x depth 8' 2"
Master Bathroom:
273 sq/ft width 15' 2" x depth 18'
Master Suite:
273 sq/ft width 15' 2" x depth 18'
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. **
- Kitchen and bath elevations: The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
