PLAN 117-267

Key Specs

2969
sq ft

3
Beds

2.5
Baths

2
Floors

0
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.

Modify This Plan

Floor Plans

Floor Plan - Other Floor Plan

Reverse

Modern Floor Plan - Other Floor Plan Plan #117-267

Floor Plan - Lower Floor Plan

Reverse

Modern Floor Plan - Lower Floor Plan Plan #117-267

Floor Plan - Main Floor Plan

Reverse

Modern Floor Plan - Main Floor Plan Plan #117-267

Floor Plan - Upper Floor Plan

Reverse

Modern Floor Plan - Upper Floor Plan Plan #117-267

Full Specs & Features

Dimension

Depth : 44'
Height : 24' 10"
Width : 28'

Area

First Floor: 1232 sq/ft
Second Floor: 505 sq/ft

*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Ceiling

Main Ceiling : 9'
Upper Ceiling Ft : 9'

Roof

Primary Pitch : 12:12
Roof Framing : Truss

Exterior Wall Framing

Exterior Wall Finish : Siding
Framing : ICF
Icf

Bedroom Features

Upstairs Master Bedrooms
Walk In Closet

Kitchen Features

Eating Bar
Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer
Family Room Keeping Room
Great Room Living Room
Loft
Play Flex Room

Lot Characteristics

Suited For Narrow Lot
Suited For View Lot

Outdoor Spaces

Balcony

Rooms

Bedroom 2:

194 sq/ft width 15' 2" x depth 12' 10"

Bedroom 3:

194 sq/ft width 15' 2" x depth 12' 10"

Family Room:

420 sq/ft width 26' x depth 16' 2"

Great Room:

420 sq/ft width 26' x depth 16' 2"

Home Office:

126 sq/ft width 12' 8" x depth 10'

Kitchen:

139 sq/ft width 12' 8" x depth 11'

Master Bedroom:

205 sq/ft width 15' x depth 13' 8"

What's Included In This Plan Set

See a sample plan set

All plans are drawn at ¼” scale or larger and include :

Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
