PLAN 17-3305
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Dimension
Depth : 76' 8"
Height : 23' 2"
Width : 79' 2"
Height : 23' 2"
Width : 79' 2"
Area
First Floor: 1861 sq/ft height 9'
Garage: 756 sq/ft height 9'
Porch: 757 sq/ft
Second Floor: 1142 sq/ft height 8'
Garage: 756 sq/ft height 9'
Porch: 757 sq/ft
Second Floor: 1142 sq/ft height 8'
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 10:12
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : Wood - 2x4
Framing : Wood - 2x4
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Walk In Closet
Kitchen Features
Kitchen Island
Additional Room Features
Great Room Living Room
Loft
Main Floor Laundry
Loft
Main Floor Laundry
Outdoor Spaces
Balcony
Covered Rear Porch
Wrap Around Porch
Covered Rear Porch
Wrap Around Porch
Rooms
Bedroom 2:
132 sq/ft width 11' x depth 12'
Bedroom 3:
238 sq/ft width 18' 4" x depth 13'
Bedroom 4:
216 sq/ft width 13' 6" x depth 16'
Covered Porch:
142 sq/ft width 8' x depth 17' 9"
Dining Room:
164 sq/ft width 12' 4" x depth 13' 4"
Foyer:
74 sq/ft width 8' x depth 9' 4"
Garage:
576 sq/ft width 24' x depth 24'
Garage Storage:
136 sq/ft width 24' x depth 5' 8"
Great Room:
428 sq/ft width 23' 10" x depth 18'
Kitchen:
225 sq/ft width 15' x depth 15'
Laundry Room:
61 sq/ft width 9' 7" x depth 6' 5"
Loft:
233 sq/ft width 24' 2" x depth 9' 8"
Master Bathroom:
162 sq/ft width 12' 6" x depth 13'
Master Closet:
81 sq/ft width 7' 8" x depth 10' 7"
Master Suite:
247 sq/ft width 19' x depth 13'
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. **
- Kitchen and bath elevations: The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
