PLAN 70-635
Key Specs
3033
sq ft
4
Beds
3.5
Baths
2
Floors
3
Garages
Cost to Build Reports Only $9.99 with Code CTB2021 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Phone: 1-888-447-1946
See our Terms & Conditions and Privacy Policy.
PLAN 70-635
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Height : 32'
Width : 61'
Second Floor: 1554 sq/ft
Roof Framing : Truss
Roof Type : Shingle
Secondary Pitch : 8:12
Framing : 2"x6"
Walk In Closet
Butler's Pantry
Kitchen Island
Great Room Living Room
Loft
Master Sitting Area
Side Entry Garage
Suited For View Lot
Covered Front Porch
3rd BR Closet:
18 sq/ft width 8' 9" x depth 2' 2"
Basement Foundation:
1767 sq/ft width 39' x depth 45' 4"
Bathroom 2:
76 sq/ft width 12' 8" x depth 6'
Bathroom 3:
40 sq/ft width 8' x depth 5'
Bedroom 2:
150 sq/ft width 12' 6" x depth 12'
Bedroom 2 Closet:
17 sq/ft width 8' 8" x depth 2'
Bedroom 3:
147 sq/ft width 13' x depth 11' 4"
Bedroom 3 Closet:
17 sq/ft width 8' 8" x depth 2'
Bedroom 4:
160 sq/ft width 13' x depth 12' 4"
Bedroom 4 Closet:
15 sq/ft width 3' x depth 5'
Breakfast Room:
114 sq/ft width 12' x depth 9' 6"
Den/Office or Bedroom 1:
149 sq/ft width 13' x depth 11' 6"
Dining Room:
205 sq/ft width 12' 4" x depth 16' 8"
Foyer:
116 sq/ft width 8' 4" x depth 14'
Garage:
743 sq/ft width 21' 8" x depth 34' 4"
Grand Room:
256 sq/ft width 16' x depth 16'
Hall:
75 sq/ft width 21' 8" x depth 3' 6"
Hall Closet:
10 sq/ft width 5' x depth 2' 2"
Kitchen:
147 sq/ft width 12' 8" x depth 11' 8"
Laundry Room:
45 sq/ft width 6' 2" x depth 7' 4"
Master Bathroom:
146 sq/ft width 11' x depth 13' 4"
Master Bedroom:
226 sq/ft width 16' x depth 14' 2"
Master Closet:
37 sq/ft width 7' x depth 5' 4"
Porch - Front:
240 sq/ft width 31' x depth 7' 9"
Powder Room:
34 sq/ft width 6' 2" x depth 5' 8"
Slab Foundation:
787 sq/ft width 21' 8" x depth 36' 4"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
| 5 Copy Set : $1112.00 |
5 printed plan sets mailed to you. |
| 8 Copy Set : $1158.00 |
8 printed plan sets mailed to you. |
| PDF Set : $1397.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| Reproducible Set : $1397.00 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
| CAD Set : $2224.00 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
| Basement: $0.00 |
Ideal for level lot, lower level of home partially or fully underground. |
| Crawlspace: $335.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
| Slab: $335.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
Additional Options
| Right-Reading Reverse : $335.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Additional Construction Sets : $65.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design : $200.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
| Mirror Reversed Sets : $55.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
