PLAN 70-742
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 32'
Height : 28'
Width : 61' 4"
Area
First Floor: 593 sq/ft
First Floor: 593 sq/ft
Garage: 263 sq/ft
Garage: 263 sq/ft
Second Floor: 950 sq/ft
Second Floor: 950 sq/ft
Ceiling
Main Ceiling : 8'
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Siding/Stone
Framing : 2"x4"
Additional Room Features
Family Room Keeping Room
Storage Area
Garage Features
Garage Under
Lot Characteristics
Suited For View Lot
Rooms
Bathroom 2:
44 sq/ft width 8' 8" x depth 5' 1"
Bathroom 2:
44 sq/ft width 8' 8" x depth 5' 1"
Bedroom 2:
150 sq/ft width 14' 1" x depth 10' 8"
Bedroom 2:
150 sq/ft width 14' 1" x depth 10' 8"
Bedroom 3:
117 sq/ft width 10' 4" x depth 11' 4"
Bedroom 3:
117 sq/ft width 10' 4" x depth 11' 4"
Deck:
120 sq/ft width 10' x depth 12'
Deck:
120 sq/ft width 10' x depth 12'
Dining Room:
143 sq/ft width 14' 4" x depth 10'
Dining Room:
143 sq/ft width 14' 4" x depth 10'
Family Room:
224 sq/ft width 14' x depth 16'
Family Room:
224 sq/ft width 14' x depth 16'
Garage:
256 sq/ft width 12' 10" x depth 20'
Garage:
256 sq/ft width 12' 10" x depth 20'
Kitchen:
108 sq/ft width 10' 4" x depth 10' 6"
Kitchen:
108 sq/ft width 10' 4" x depth 10' 6"
Laundry Room:
50 sq/ft width 5' 4" x depth 9' 5"
Laundry Room:
50 sq/ft width 5' 4" x depth 9' 5"
Living Room:
169 sq/ft width 16' 2" x depth 10' 6"
Living Room:
169 sq/ft width 16' 2" x depth 10' 6"
Master Bathroom:
47 sq/ft width 9' 5" x depth 5'
Master Bathroom:
47 sq/ft width 9' 5" x depth 5'
Master Bedroom:
175 sq/ft width 12' 11" x depth 13' 7"
Master Bedroom:
175 sq/ft width 12' 11" x depth 13' 7"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
Plan Set
$1238.00
$1288.00
$1552.00
$1552.00
$2476.00
Foundation
$0.00
$650.00
$650.00
Additional Options
$395.00
$80.00
$165.00
$395.00
$39.00
$165.00
$75.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
