PLAN 1057-19

Home Plan - Craftsman Exterior - Front Elevation Plan #1057-19
Home Plan - Craftsman Exterior - Rear Elevation Plan #1057-19

Key Specs


Plan Sq Ft

3164
sq ft

Plan Bedrooms

4
Beds

Plan Bathrooms

3.5
Baths

Plan Floors

2
Floors

Plan Garages

2
Garages

Select Plan Set Options

What's included?
Right-Reading Reverse
$425.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Use License
$1020.00
Additional Use License.
Audio Video Design
$85.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide
$33.15
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Subtotal
NOW $1785.00
You save $315.00
(15% savings)
Sale ends soon!
Also order by phone: 1-888-447-1946
Cost-to-Build Estimates
Cost to Build Reports Only $9.99 with Code CTB2021 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Questions about building your home?
Questions?
Send me your Newsletter, too!
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-888-447-1946
Hours:  Mon-Fri, 9AM - 8:30PM (EST)

See our Terms & Conditions and Privacy Policy.

PLAN 1057-19

Key Specs


Plan Sq Ft

3164
sq ft

Plan Bedrooms

4
Beds

Plan Bathrooms

3.5
Baths

Plan Floors

2
Floors

Plan Garages

2
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.

Plan Description


This narrow lot Farmhouse design is packed with great living space. The main floor is open for allowing great entraining and socializing. The home is equipped with a large working panty with a swing up window for entertaining out the covered porch. The upper level contains 4 bedrooms with 3 baths. The master suite with large duel closets. Every bedroom has a step up ceiling making each room feel even larger. Great home for the small lake lot with a sloping grade.

Full Specs & Features


Dimension
Depth : 65' 10"
Height : 38'
Width : 40' 6"
Area
Basement : 1213 sq/ft
Decks : 332 sq/ft
Garage : 490 sq/ft
Main Floor : 1316 sq/ft
Porch : 400 sq/ft
Storage : 415 sq/ft
Upper Floor : 1848 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Ceiling Details : Tray and step ceilings on all bedrooms
Garage Ceiling : 10' 6"
Lower Ceiling : 10'
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 7.5/12
Roof Framing : wood
Roof Type : trusses
Secondary Pitch : 12/12
Exterior Wall Framing
Exterior Wall Finish : Board and batten, horizontal siding and stone veneer
Framing : 2x6 wood
Insulation : 21
Bedroom Features
Upstairs Bedrooms
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Mud Room
Storage Area
Unfinished Future Space
Upstairs Laundry
Garage Features
Front Entry Garage
Lot Characteristics
Suited For Narrow Lot
Suited For Sloping Lot
Suited For View Lot
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
More
Jack & Jill Bath

What's Included In This Plan Set


All plans are drawn at ¼” scale or larger and include :
  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
» See important information before purchasing.
Questions? Call 1-888-447-1946
Plan Set
PDF Set :
$1785.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
CAD Set :
$2040.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.
PDF Unlimited Build :
$6800.00
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
CAD Unlimited Build :
$7650.00
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Foundation

Walk Out Basement:
$0.00
Ideal for a sloping lot, lower level with outdoor access.
Basement:
$425.00
Ideal for level lot, lower level of home partially or fully underground.
Crawlspace:
$425.00
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.
Daylight Basement:
$425.00
Ideal for sloping lot, lower level of home partially underground.
Slab:
$425.00
Ideal for level lot, single layer concrete poured directly on grade.

Framing

Wood 2x6:
$0.00
Wood 2x6
Wood 2x4:
$425.00
Wood 2x4

Additional Options

Right-Reading Reverse :
$425.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Use License :
$1020.00
Additional Use License.
Audio Video Design :
$85.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide :
$33.15
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.

*Alternate Foundations may take time to prepare.

*Options with a fee may take time to prepare. Please call to confirm.
