PLAN 70-696
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 48'
Height : 33' 8"
Width : 71'
Area
First Floor: 1889 sq/ft
Second Floor: 1674 sq/ft
Ceiling
Main Ceiling : 9'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Shingle/Stone
Framing : 2"x6"
Bedroom Features
Upstairs Master Bedrooms
Walk In Closet
Kitchen Features
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Loft
Storage Area
Sunroom
Garage Features
Oversized Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Balcony
Screened Porch
Wrap Around Porch
More
Jack & Jill Bath
Rooms
Basement Foundation:
3408 sq/ft width 71' x depth 48'
Bathroom 2:
44 sq/ft width 8' 4" x depth 5' 4"
Bathroom 3:
44 sq/ft width 8' 4" x depth 5' 4"
Bedroom 2:
210 sq/ft width 14' 6" x depth 14' 6"
Bedroom 2 Closet:
43 sq/ft width 9' x depth 4' 10"
Bedroom 3:
232 sq/ft width 14' 6" x depth 16'
Bedroom 3 Closet:
43 sq/ft width 9' x depth 4' 10"
Deck:
151 sq/ft width 15' 8" x depth 9' 8"
Dining Room:
191 sq/ft width 14' x depth 13' 8"
Family Room:
337 sq/ft width 19' x depth 17' 9"
Foyer:
91 sq/ft width 8' 4" x depth 11'
Garage:
770 sq/ft width 22' x depth 35'
Hall:
22 sq/ft width 6' 5" x depth 3' 7"
Hall Closet:
18 sq/ft width 9' 4" x depth 2'
Hall Closet 1:
6 sq/ft width 2' x depth 3'
Hall Closet 2:
12 sq/ft width 6' 5" x depth 2'
Kitchen:
207 sq/ft width 14' 4" x depth 14' 6"
Laundry Room:
87 sq/ft width 12' x depth 7' 4"
Library:
188 sq/ft width 14' 6" x depth 13'
Loft:
255 sq/ft width 21' 4" x depth 12'
Master Bathroom:
253 sq/ft width 17' 7" x depth 14' 5"
Master Bedroom:
290 sq/ft width 20' x depth 14' 6"
Master Closet:
37 sq/ft width 6' x depth 6' 4"
Master Closet Two:
37 sq/ft width 6' x depth 6' 4"
Mud Room:
80 sq/ft width 9' 4" x depth 8' 8"
Pantry:
30 sq/ft width 6' 4" x depth 4' 10"
Porch - Front:
992 sq/ft width 51' 4" x depth 19' 4"
Porch - Screened:
113 sq/ft width 10' 8" x depth 10' 8"
Powder Room:
21 sq/ft width 7' 4" x depth 3'
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
