PLAN 70-539
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Floor Plans
Full Specs & Features
Dimension
Depth : 94' 10"
Height : 35'
Width : 75' 10"
Area
Bonus: 805 sq/ft
First Floor: 2733 sq/ft
Second Floor: 1067 sq/ft
Roof
Primary Pitch : 12:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Siding
Framing : 2"x6"
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Hobby Rec Room Game Room
Loft
Media Room
Play Flex Room
Storage Area
Sunroom
Unfinished Future Space
Workshop
Garage Features
Oversized Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For View Lot
Outdoor Spaces
Balcony
Covered Front Porch
Covered Rear Porch
Screened Porch
More
Jack & Jill Bath
Rooms
Bedroom 2:
224 sq/ft width 12' x depth 18' 8"
Bedroom 3:
142 sq/ft width 13' 2" x depth 10' 10"
Bedroom 4:
175 sq/ft width 11' 4" x depth 15' 6"
Bonus Room - Finished:
810 sq/ft width 15' x depth 54'
Breakfast Room:
144 sq/ft width 10' 8" x depth 13' 6"
Dining Room:
199 sq/ft width 13' 4" x depth 15'
Garage:
1125 sq/ft width 28' 6" x depth 39' 6"
Kitchen:
144 sq/ft width 10' 8" x depth 13' 6"
Living Room:
266 sq/ft width 16' 4" x depth 16' 4"
Master Bathroom:
143 sq/ft width 10' x depth 14' 4"
Master Bedroom:
242 sq/ft width 14' x depth 17' 4"
Master Closet:
114 sq/ft width 14' 4" x depth 8'
Study:
200 sq/ft width 12' x depth 16' 8"
Wood Deck:
100 sq/ft width 8' 10" x depth 11' 4"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
Plan Set
$1722.95
$2427.60
$3131.40
$3131.40
$5479.95
Foundation
$0.00
$318.75
$318.75
Additional Options
$318.75
$68.00
$85.00
$33.15
$51.00
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
