PLAN 1039-5

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.

Modify This Plan

Plan Description

This Italian Renaissance-style home starts with a magnificent stucco exterior, Spanish-style roof, and Old World details, such as arches and accent niches. This five-bedroom, four-bath masterpiece caters to an open layout--boasting high ceilings, windowed walls, and views throughout the home of the luxurious pool and covered lanai. Family and friends will enter this stunning home through the expansive foyer. The foyer stretches into the parlor, featuring sweeping views to the lanai and access to the backyard. The entrance is flanked by a study that can be converted into a fourth bedroom, and a formal dining room. There is also a convenient service entrance accessible from the three-car garage. The elegant dining room is open to the foyer and boasts views of the front yard. The study is accessed through double doors, as it requires more privacy whether it is used as a bedroom or home office. The master wing features His and Hers walk-in closets and a lavish bath with His and Hers vanities. A sitting room extends the master bedroom out ot the lanai with poolside views. Homeowners can enjoy a cool drink from the juice bar located in the master suite. The opposite wing is host to two additional suites, conveniently placed away from the master suite to ensure privacy for both the homeowners and visitors. The family room is sure to be the hub of activity, with a built-in entertainment center and views of the backyard pool through oversized windows. The family room also opens to the lanai, and a summer kitchen is optional. Meals can be prepared in the gourmet kitchen, complete with a work island, and enjoyed in the connecting breakfast nook or adjacent family room. Upstairs reside a spacious bonus room and connecting bathroom--perfect for a guest suite or a family bedroom. This spacious home is ideal for empty-nesters who enjoy the one-floor layout with plenty of space, or a large family who embraces the convenience of one-level design.

Full Specs & Features


Depth : 60'

Height : 27'

Width : 86' 4"


First Floor: 3437 sq/ft

Second Floor: 420 sq/ft

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.


Primary Pitch : 7:12

Roof Framing : Truss

Roof Type : Tile

Exterior Wall Framing

Exterior Wall Finish : Stucco

Framing : Block

Bedroom Features


Formal Dining Room

Formal Living Room / Parlor

Guest Suite

Split Bedrooms

Kitchen Features

Breakfast Nook

Kitchen Island

Walk In Pantry Cabinet Pantry

Additional Room Features

Family Room Keeping Room

Main Floor Laundry

Master Sitting Area

Open Floor Plan

Storage Area

Garage Features

Side Entry Garage

Outdoor Spaces


Covered Rear Porch

Outdoor Kitchen Grill

What's Included In This Plan Set

All plans are drawn at ¼” scale or larger and include :

  • Foundation Plan: Drawn to 1/4" scale, this page shows all necessary notations and dimensions including support columns, walls and excavated and unexcavated areas.
  • Exterior Elevations: A blueprint picture of all four sides showing exterior materials and measurements.
  • Floor Plan(s): Detailed plans, drawn to 1/4" scale for each level showing room dimensions, wall partitions, windows, etc. as well as the location of electrical outlets and switches.
  • Cross Section: A vertical cutaway view of the house from roof to foundation showing details of framing, construction, flooring and roofing.
  • Interior Elevations: Detailed drawings of kitchen cabinet elevations and other elements as required.
