PLAN 70-1128

Ranch Exterior - Front Elevation Plan #70-1128
Ranch Exterior - Rear Elevation Plan #70-1128

Select Plan Set Options

What's included?
Additional Construction Sets
$45.00/each
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Mirror Reversed Sets
$36.00
Printed sets showing plan in reverse, text and dimensions will be backwards.
Subtotal
NOW $1458.00
You save $162.00
(10% savings)
Sale ends soon!
Also order by phone: 1-888-447-1946
Cost-to-Build Estimates
How much will this cost to build?
This report will provide you cost estimates based on location and building materials.
Questions about building your home?
Questions?
Send me your Newsletter, too!
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-888-447-1946
Hours:  Mon-Fri, 9AM - 8:30PM (EST)

See our Terms & Conditions and Privacy Policy.

PLAN 70-1128

Key Specs


3858
sq ft

4
Beds

2.5
Baths

1
Floors

4
Garages

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.

Plan Description


A hip roofline defines that tone of this spacious walkout ranch. As you enter you’ll be enthralled with the circular staircase with a two-story ceiling that leads to the lower level along with the multiple step ceilings found throughout the home. The main living area is found at the back of the home where a spacious kitchen with island bar overlooks the great room and nook to create an open plan where you can spread out and stay within site. A formal dining room is located to your left as you enter the home with a den opposite to your right where French doors add charm to the space. The master suite is found to the right of the design and pampers with a large walk-in closet, step ceiling and dual sinks. Three additional bedrooms, a game room, family room and wet bar are located in the lower level. A three-stall, side-load garage completes the home.

Full Specs & Features


Dimension
Depth : 57' 4"
Height : 24' 1"
Width : 71' 4"
Area
Basement Living: 1610 sq/ft height 8' 9"
First Floor: 2248 sq/ft height 10' 1"
Garage: 912 sq/ft
*Total Square Footage only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Ceiling Details : 10'. Entry/Grt Rm 12' Step, Kitch/Nook/Din Rm/Den/Master Bdrm 10' Step
Lower Ceiling : 9'
Main Ceiling : 10'
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Roof Load : 47 psf
Roof Type : Asphalt
Secondary Pitch : 8:12
Exterior Wall Framing
Exterior Wall Finish : Stucco, Stone, Siding
Framing : 2x6
Bedroom Features
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Butler's Pantry
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Great Room Living Room
Hobby Rec Room Game Room
Main Floor Laundry
Storage Area
Unfinished Future Space
Wet Bar
Garage Features
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For Sloping Lot
Outdoor Spaces
Covered Rear Porch
Rooms

Bedroom 2:

width 13' x depth 13' 6"

Bedroom 3:

width 13' 6" x depth 13'

Bedroom 4:

width 13' 4" x depth 14'

Den:

width 12' 8" x depth 11' 8"

Dining Room:

width 12' x depth 13'

Family Room:

width 18' x depth 21' 4"

Game Room:

width 15' x depth 14'

Garage:

912 sq/ft width 21' 8" x depth 39'

Great Room:

width 15' 8" x depth 17'

Kitchen:

width 15' 8" x depth 13'

Master Bedroom:

width 14' x depth 15' 4"

Nook:

width 15' 8" x depth 11' 8"

Storage:

width 8' x depth 8'

What's Included In This Plan Set


  • Cover sheet with front rendering
  • Foundation and floor plans at 1/4" = 1' scale
  • Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
  • Building sections and details as required to construct the individual design
  • Interior elevation of cabinets at 1/4" = 1' scale
  • Roof plans
  • Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
  • Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
  • Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
» See important information before purchasing.
Questions? Call 1-888-447-1946
Plan Set
5 Copy Set :
$1458.00
5 printed plan sets mailed to you.
8 Copy Set :
$1528.20
8 printed plan sets mailed to you.
PDF Set :
$1909.80
PDF plan sets are best for fast electronic delivery and inexpensive local printing.
Reproducible Set :
$1909.80
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper.
CAD Set :
$3055.50
For use by design professionals to make substantial changes to your house plan and inexpensive local printing.

Foundation

Basement:
$0.00
Ideal for level lot, lower level of home partially or fully underground.
Crawlspace:
$301.50
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”.
Slab:
$301.50
Ideal for level lot, single layer concrete poured directly on grade.

Additional Options

Right-Reading Reverse :
$265.50
Choose this option to reverse your plans and to have the text and dimensions readable.
Additional Construction Sets :
$45.00
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date).
Audio Video Design :
$90.00
Receive an overlay sheet with suggested placement of audio and video components.
Construction Guide :
$35.10
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design :
$180.00
Receive an overlay sheet with suggested placement of lighting fixtures.
Mirror Reversed Sets :
$36.00
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected.
