PLAN 70-545
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Floor Plans
Full Specs & Features
Dimension
Depth : 65'
Height : 36'
Width : 73' 8"
Area
First Floor: 2665 sq/ft
Second Floor: 1496 sq/ft
Ceiling
Ceiling Details : Great Room & Entry: 2-StoryMaster: 12' Tray Study: Step
Main Ceiling : 10'
Upper Ceiling Ft : 8'
Roof
Primary Pitch : 8:12
Roof Framing : Truss
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Stucco
Framing : 2"x6"
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Great Room Living Room
Loft
Unfinished Future Space
Garage Features
Oversized Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For Sloping Lot
Suited For View Lot
Outdoor Spaces
Balcony
Covered Front Porch
Covered Rear Porch
More
Jack & Jill Bath
Rooms
Bedroom 2:
214 sq/ft width 15' x depth 14' 4"
Bedroom 3:
304 sq/ft width 24' x depth 12' 8"
Bedroom 4:
208 sq/ft width 16' x depth 13'
Breakfast Room:
201 sq/ft width 11' 10" x depth 17'
Dining Room:
212 sq/ft width 14' 2" x depth 15'
Garage:
856 sq/ft width 24' x depth 35' 8"
Gathering Room:
387 sq/ft width 18' x depth 21' 6"
Kitchen:
206 sq/ft width 10' 2" x depth 20' 4"
Master Bedroom:
322 sq/ft width 14' x depth 23'
Study:
168 sq/ft width 12' x depth 14'
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
Plan Set
$1773.00
$2498.00
$3224.00
$3224.00
$5641.00
Foundation
$0.00
$375.00
$375.00
Additional Options
$375.00
$80.00
$100.00
$39.00
$60.00
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
