PLAN 120-188
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Dimension
Depth : 117' 5"
Height : 23' 10"
Width : 88'
Height : 23' 10"
Width : 88'
Area
Basement Living: 626 sq/ft
First Floor: 3636 sq/ft
Garage: 922 sq/ft
Main Floor: 3636 sq/ft
First Floor: 3636 sq/ft
Garage: 922 sq/ft
Main Floor: 3636 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Ceiling
Ceiling Details : Family – 13’, Kitchen/Nook – 13’, Master BR – 13’, Master Bath/WIC – 12’, Foyer – 13’, BR2 – 13’, Den/BR3/Bath2 – 10’, Lower Level - 9’, Garage – 10’.
Main Ceiling : 13'
Main Ceiling : 13'
Roof
Primary Pitch : 3:12
Roof Framing : Stick
Roof Load : 20 lbs
Roof Type : Build-Up
Secondary Pitch : 0:12
Roof Framing : Stick
Roof Load : 20 lbs
Roof Type : Build-Up
Secondary Pitch : 0:12
Exterior Wall Framing
Exterior Wall Finish : Stone/Stucco
Framing : 2x6
Insulation : R-19
Framing : 2x6
Insulation : R-19
Bedroom Features
Main Floor Bedrooms
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Main Floor Laundry
Family Room Keeping Room
Hobby Rec Room Game Room
Main Floor Laundry
Garage Features
Side Entry Garage
Outdoor Spaces
Covered Rear Porch
Grill Deck Sundeck
Grill Deck Sundeck
Rooms
Bedroom 2:
width 14' x depth 12'
Bedroom 2 Closet:
width 6' x depth 7'
Bedroom 3:
width 14' x depth 11' 6"
Bedroom 3 Closet:
width 6' 8" x depth 6'
Covered Front Porch:
71 sq/ft
Den:
width 14' x depth 14' 3"
Family Room:
width 20' x depth 29'
First Floor:
3636 sq/ft
Foyer:
width 10' x depth 14'
Game Room:
width 14' x depth 17' 9"
Garage:
922 sq/ft width 25' 5" x depth 35' 8"
Home Office:
width 13' x depth 14' 4"
Kitchen:
width 16' 10" x depth 29'
Lanai:
1124 sq/ft width 25' x depth 44'
Main Floor:
3636 sq/ft
Master Closet:
width 11' x depth 21'
Master Suite:
width 18' x depth 18'
Nook:
width 11' 8" x depth 12'
Powder Room:
width 7' x depth 7' 8"
Utility Room:
width 14' x depth 17' 8"
What's Included In This Plan Set
- Designer offers a 2nd Build License for $395 with a PDF purchase as well as an Unlimited License for $395 with the purchase of a CAD.
- Floor Plans – ¼”=1’-0” scale floor plan indicating location of frame and masonry walls, support members, doors, windows, plumbing fixtures, cabinets, shelving, ceiling conditions and notes deemed relevant to this plan.
- Exterior Elevations – All elevations at ¼” = 1’-0” scale in most cases. Some older designs may contain 1/8” scale side and rear elevations. Drawing will indicate overall configuration of home at each side view and make note of plate heights, roof overhangs, window header heights, roof pitches, materials used and extent to which they are used and enlargement of any details we feel necessary to explain the construction.
- Building Sections – ¼” = 1’-0” building sections are included when there is no other reasonable way to indicate the volumetric/height conditions in the home. Most of this information can usually be determined from the exterior elevations.
- Cabinet Elevations – 3/8” = 1’-0” scale elevations indicating configuration of cabinets, heights, widths, type of components used, cabinet material and finish, counter surfaces, appliances.
- Framing Plans – ¼” – 1’-0” scale framing plans indicating size and spacing of members as well as bracing and blocking required for structural purposes. Local codes will most likely need to be consulted.
- Foundation Plans – ¼” = 1’-0” scale foundation plans indicating location of structural walls, grade beams, reinforcing steel and structural columns. Consulting a local engineer is advisable as well as is analysis of soil conditions on site.
- Electrical Plans – ¼” = 1’-0” scale schematic plans indicating location and types of electrical fixtures, switches, outlets, and how they are to be switched.
