PLAN 17-3328
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.Plan Description
Beautiful rooflines add touches of European style to this New American home. The island-style kitchen has plenty of counterspace, a breakfast bar, and a large breakfast room. Open to the kitchen, the great room has a corner fireplace. The master suite is located in a private corner behind the great room. Upstairs, relax in the home theater. Three bedrooms share two full baths. Over the garage, bonus space is available for future expansion.
Full Specs & Features
Dimension
Depth : 84' 2"
Height : 37' 6"
Width : 112' 2"
Height : 37' 6"
Width : 112' 2"
Area
Bonus: 677 sq/ft
First Floor: 2666 sq/ft height 10'
Garage: 1061 sq/ft
Porch: 626 sq/ft
Second Floor: 1712 sq/ft height 9'
First Floor: 2666 sq/ft height 10'
Garage: 1061 sq/ft
Porch: 626 sq/ft
Second Floor: 1712 sq/ft height 9'
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 12:12
Roof Framing : Combination Truss/Conventional
Roof Type : Shingle
Roof Framing : Combination Truss/Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick/Stone
Framing : Wood - 2x4
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Main Floor Master Bedroom
Walk In Closet
Formal Dining Room
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Kitchen Island
Kitchenette Wet Bar
Additional Room Features
Great Room Living Room
Unfinished Future Space
Workshop
Unfinished Future Space
Workshop
Outdoor Spaces
Covered Front Porch
Covered Rear Porch
Covered Rear Porch
Rooms
Bedroom 2:
177 sq/ft width 13' 4" x depth 13' 4"
Bedroom 3:
175 sq/ft width 13' 4" x depth 13' 2"
Bedroom 4:
159 sq/ft width 12' x depth 13' 3"
Bonus Room - Unfinished:
626 sq/ft width 15' 8" x depth 40'
Breakfast Room:
172 sq/ft width 14' x depth 12' 4"
Dining Room:
173 sq/ft width 13' x depth 13' 4"
Garage:
941 sq/ft width 23' 4" x depth 40' 4"
Great Room:
357 sq/ft width 19' x depth 18' 10"
Grilling Porch:
378 sq/ft width 27' x depth 14'
Home Theater:
251 sq/ft width 19' x depth 13' 3"
Kitchen:
240 sq/ft width 16' x depth 15'
Laundry Room:
76 sq/ft width 8' 8" x depth 8' 10"
Master Bathroom:
198 sq/ft width 12' x depth 16' 6"
Master Suite:
253 sq/ft width 16' 4" x depth 15' 6"
Study:
173 sq/ft width 13' x depth 13' 4"
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. **
- Kitchen and bath elevations: The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
