PLAN 17-2775
Key Specs
4510
sq ft
4
Beds
4.5
Baths
1
Floors
2
Garages
Cost to Build Reports Only $9.99 with Code CTB2021 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Get Cost-To-Build Report
Or order by phone: 1-888-447-1946
Questions?
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-888-447-1946
Phone: 1-888-447-1946
Hours: Mon-Fri, 9AM - 8:30PM (EST)
See our Terms & Conditions and Privacy Policy.
PLAN 17-2775
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Dimension
Depth : 65'
Height : 32' 4"
Width : 77' 10"
Height : 32' 4"
Width : 77' 10"
Area
Basement Living: 1501 sq/ft height 8'
First Floor: 3009 sq/ft height 9'
Porch: 630 sq/ft
Storage: 898 sq/ft
First Floor: 3009 sq/ft height 9'
Porch: 630 sq/ft
Storage: 898 sq/ft
* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.
Roof
Primary Pitch : 10:12
Roof Framing : Combination Truss/Conventional
Roof Type : Shingle
Roof Framing : Combination Truss/Conventional
Roof Type : Shingle
Exterior Wall Framing
Exterior Wall Finish : Brick
Framing : Wood - 2x4
Framing : Wood - 2x4
Bedroom Features
Fireplace
Formal Dining Room
Guest Suite
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Formal Dining Room
Guest Suite
Main Floor Master Bedroom
Split Bedrooms
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Kitchen Island
Kitchenette Wet Bar
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Exercise Room
Great Room Living Room
Hobby Rec Room Game Room
Main Floor Laundry
Media Room
Wine Cellar
Exercise Room
Great Room Living Room
Hobby Rec Room Game Room
Main Floor Laundry
Media Room
Wine Cellar
Garage Features
Side Entry Garage
Outdoor Spaces
Courtyard
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
Covered Front Porch
Covered Rear Porch
Grill Deck Sundeck
Rooms
Bedroom 2:
207 sq/ft width 14' 4" x depth 14' 6"
Bedroom 3:
341 sq/ft width 20' 8" x depth 16' 6"
Bedroom 4:
332 sq/ft width 20' 2" x depth 16' 6"
Breakfast Area:
161 sq/ft width 15' 2" x depth 10' 8"
Dining Room:
226 sq/ft width 12' 4" x depth 18' 4"
Exercise Room:
136 sq/ft width 13' 8" x depth 10'
Foyer:
102 sq/ft width 9' 4" x depth 11'
Garage:
877 sq/ft width 31' 2" x depth 28' 2"
Great Room:
360 sq/ft width 18' 8" x depth 19' 4"
Grilling Porch:
582 sq/ft width 38' x depth 15' 4"
Home Theater:
517 sq/ft width 22' 2" x depth 23' 4"
Kitchen:
237 sq/ft width 15' 2" x depth 15' 8"
Laundry Room:
144 sq/ft width 18' 10" x depth 7' 8"
Master Bathroom:
254 sq/ft width 19' 10" x depth 12' 10"
Master Bedroom:
354 sq/ft width 24' 2" x depth 14' 8"
Patio:
100 sq/ft width 10' x depth 10'
Wine Cellar:
63 sq/ft width 9' 6" x depth 6' 8"
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. **
- Kitchen and bath elevations: The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
Questions? Call 1-888-447-1946
Plan Set
