PLAN 17-3320
Key Specs
4886
sq ft
4
Beds
4
Baths
2
Floors
3
Garages
Cost to Build Reports Only $9.99 with Code CTB2021 (Limit 1 Per Order)
This report will provide you cost estimates based on location and building materials.
Phone: 1-888-447-1946
See our Terms & Conditions and Privacy Policy.
PLAN 17-3320
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Width : 96' 10"
Garage: 885 sq/ft
Porch: 569 sq/ft
Second Floor: 800 sq/ft
Framing : Wood - 2x4
Formal Living Room / Parlor
Main Floor Master Bedroom
Kitchen Island
Exercise Room
Family Room Keeping Room
Hobby Rec Room Game Room
Master Sitting Area
Bathroom 2:
79 sq/ft width 6' x depth 13' 2"
Bedroom 2:
190 sq/ft width 13' x depth 14' 8"
Bedroom 3:
221 sq/ft width 12' 4" x depth 18'
Breakfast Room:
115 sq/ft width 9' 4" x depth 12' 4"
Dining Room:
173 sq/ft width 13' x depth 13' 4"
Exercise Room:
192 sq/ft width 12' 10" x depth 15'
Foyer:
91 sq/ft width 10' 2" x depth 9'
Game Room:
456 sq/ft width 24' x depth 19'
Garage:
810 sq/ft width 23' 10" x depth 34'
Guest Bedroom:
200 sq/ft width 14' 8" x depth 13' 8"
Hearth Room:
311 sq/ft width 17' 4" x depth 18'
Kitchen:
255 sq/ft width 15' x depth 17'
Lanai:
610 sq/ft width 40' 8" x depth 15'
Laundry Room:
159 sq/ft width 11' 8" x depth 13' 8"
Living Room:
445 sq/ft width 22' 10" x depth 19' 6"
Master Bathroom:
245 sq/ft width 11' 8" x depth 21'
Master Sitting Area:
109 sq/ft width 15' x depth 7' 4"
Master Suite:
240 sq/ft width 15' x depth 16'
Porch - Front:
100 sq/ft width 16' 4" x depth 6' 2"
Study:
180 sq/ft width 12' x depth 15'
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. **
- Kitchen and bath elevations: The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
| PDF Set : $1650.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| 5 Copy Set : $1750.00 |
5 printed plan sets mailed to you. |
| 5 Copy and PDF Set : $2000.00 |
5 printed plan sets mailed to you plus PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| CAD Set : $3300.00 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
| Crawlspace: $0.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
| Slab: $0.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
| Basement: $299.00 |
Ideal for level lot, lower level of home partially or fully underground. |
Framing
| Wood 2x4: $0.00 |
Wood 2x4 |
| Wood 2x6: $299.00 |
Wood 2x6 |
Additional Options
| Right-Reading Reverse : $199.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Additional Construction Sets : $75.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Lighting Design : $200.00 |
Receive an overlay sheet with suggested placement of lighting fixtures. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
