PLAN 70-853
Cost to Build Reports Only $9.99 with Code CTB2022 (Limit 1)
This report will provide you cost estimates based on location and building materials.
Get Personalized Help
Phone: 1-888-447-1946
See our Terms & Conditions and Privacy Policy.
PLAN 70-853
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Full Specs & Features
Height : 33' 10"
Width : 112' 7"
Garage: 826 sq/ft
Second Floor: 1631 sq/ft
Upper Ceiling Ft : 9'
Roof Framing : Truss
Roof Type : Shingle
Secondary Pitch : 8:12
Framing : 2"x6"
Walk In Closet
Eating Bar
Kitchen Island
Walk In Pantry Cabinet Pantry
Family Room Keeping Room
Great Room Living Room
Loft
Storage Area
Sunroom
Screened Porch
Basement Foundation:
8162 sq/ft width 112' 7" x depth 72' 6"
Bathroom 2:
64 sq/ft width 6' x depth 10' 8"
Bathroom 3:
118 sq/ft width 10' 4" x depth 11' 6"
Bedroom 2:
262 sq/ft width 15' x depth 17' 6"
Bedroom 2 Closet:
46 sq/ft width 8' 6" x depth 5' 6"
Bedroom 3:
140 sq/ft width 12' x depth 11' 8"
Bedroom 3 Closet:
18 sq/ft width 9' x depth 2'
Bedroom 4:
177 sq/ft width 14' x depth 12' 8"
Bedroom 4 Closet:
48 sq/ft width 5' x depth 9' 9"
Bedroom 5:
71 sq/ft width 5' 8" x depth 12' 8"
Bedroom 5 Closet:
34 sq/ft width 7' 5" x depth 4' 8"
Breakfast Room:
255 sq/ft width 17' x depth 15'
Computer Room:
130 sq/ft width 9' 4" x depth 14'
Deck:
286 sq/ft width 19' 6" x depth 14' 8"
Den:
168 sq/ft width 12' x depth 14'
Dining Room:
238 sq/ft width 14' x depth 17'
Family Room:
351 sq/ft width 17' x depth 20' 8"
Foyer:
388 sq/ft width 18' 6" x depth 21'
Garage:
808 sq/ft width 33' 8" x depth 24'
Hall:
95 sq/ft width 18' x depth 5' 4"
Hall Bathroom:
26 sq/ft width 5' 3" x depth 5'
Hall Closet:
11 sq/ft width 5' 6" x depth 2'
Kitchen:
266 sq/ft width 15' 8" x depth 17'
Laundry Room:
117 sq/ft width 10' 3" x depth 11' 6"
Living Room:
270 sq/ft width 15' x depth 18'
Master Bathroom:
191 sq/ft width 12' 9" x depth 15'
Master Bedroom:
256 sq/ft width 14' x depth 18' 4"
Master Closet:
84 sq/ft width 7' 8" x depth 11'
Master Closet Two:
43 sq/ft width 7' 8" x depth 5' 8"
Mud Room:
69 sq/ft width 7' 9" x depth 9'
Pantry:
30 sq/ft width 4' 10" x depth 6' 3"
Porch - Front:
53 sq/ft width 7' 4" x depth 7' 4"
Porch - Screened:
164 sq/ft width 13' x depth 12' 8"
Powder Room:
35 sq/ft width 5' 8" x depth 6' 3"
Utility Room:
74 sq/ft width 9' 8" x depth 7' 9"
Walk-In Closet:
55 sq/ft width 5' 4" x depth 10' 6"
Wet Bar:
69 sq/ft width 9' x depth 7' 8"
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
| 5 Copy Set : $2104.00 |
5 printed plan sets mailed to you. |
| 8 Copy Set : $2204.00 |
8 printed plan sets mailed to you. |
| PDF Set : $2755.00 |
PDF plan sets are best for fast electronic delivery and inexpensive local printing. |
| Reproducible Set : $2755.00 |
For inexpensive local printing / making minor adjustments by hand. 1 printed set, typically on Bond paper. |
| CAD Set : $4408.00 |
For use by design professionals to make substantial changes to your house plan and inexpensive local printing. |
Foundation
| Basement: $0.00 |
Ideal for level lot, lower level of home partially or fully underground. |
| Crawlspace: $335.00 |
Ideal for semi-sloped or level lot, home can be built off of grade, typically 18” - 48”. |
| Slab: $335.00 |
Ideal for level lot, single layer concrete poured directly on grade. |
Additional Options
| Right-Reading Reverse : $295.00 |
Choose this option to reverse your plans and to have the text and dimensions readable. |
| Additional Construction Sets : $50.00 |
Additional hard copies of the plan (can be ordered at the time of purchase and within 90 days of the purchase date). |
| Audio Video Design : $100.00 |
Receive an overlay sheet with suggested placement of audio and video components. |
| Construction Guide : $39.00 |
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics. |
| Mirror Reversed Sets : $40.00 |
A mirror-reversed set is a printed copy of your house, resulting in the same image you would see if you held the drawing up to a mirror. Everything, including the text, is backward in relation to the original design. These kinds of drawing are typically used to reorient an original plan more advantageously on a site, either because the homeowner prefers it that way or because of limitations of the site itself. Note: Mirror reverse sets are only available with a 5 copy or 8 copy set. With a Reproducible, PDF, or CAD set, you can print mirrored copies locally. In addition: 5 Copy set selected, should only allow 4 mirrored sets to be selected. 8 Copy set selected, should only allow 7 mirrored sets to be selected. |
*Alternate Foundations may take time to prepare.
*Options with a fee may take time to prepare. Please call to confirm.
