This brick and siding Four-plex plan has the charm of a southern traditional single-family home. Each of the four living spaces has three bedrooms with walk-in closets, and two full bathrooms. The step saver kitchen has a bar counter for additional seating.
Full Specs & Features
Width : 56'
First Floor: 1258 sq/ft
Second Floor: 1258 sq/ft
Second Floor: 1258 sq/ft
Roof Framing : Conventional
Roof Type : Asphalt
Framing : Wood - 2x4
Formal Living Room / Parlor
Main Floor Master Bedroom
Upstairs Master Bedrooms
Walk In Closet
Media Room
Covered Front Porch
Balcony:
153 sq/ft width 17' x depth 9'
Balcony:
136 sq/ft width 17' x depth 8'
Bedroom 2:
122 sq/ft width 10' 6" x depth 11' 8"
Bedroom 2:
122 sq/ft width 10' 6" x depth 11' 8"
Bedroom 2:
122 sq/ft width 10' 6" x depth 11' 8"
Bedroom 2:
122 sq/ft width 10' 6" x depth 11' 8"
Bedroom 3:
124 sq/ft width 10' 6" x depth 11' 10"
Bedroom 3:
124 sq/ft width 10' 6" x depth 11' 10"
Bedroom 3:
124 sq/ft width 10' 6" x depth 11' 10"
Bedroom 3:
124 sq/ft width 10' 6" x depth 11' 10"
Dining Room:
111 sq/ft width 12' x depth 9' 4"
Dining Room:
111 sq/ft width 12' x depth 9' 4"
Dining Room:
111 sq/ft width 12' x depth 9' 4"
Dining Room:
111 sq/ft width 12' x depth 9' 4"
Kitchen:
122 sq/ft width 10' 6" x depth 11' 8"
Kitchen:
124 sq/ft width 10' 8" x depth 11' 8"
Kitchen:
122 sq/ft width 10' 6" x depth 11' 8"
Kitchen:
122 sq/ft width 10' 6" x depth 11' 8"
Living Room:
212 sq/ft width 14' 4" x depth 14' 10"
Living Room:
212 sq/ft width 14' 4" x depth 14' 10"
Living Room:
212 sq/ft width 14' 4" x depth 14' 10"
Living Room:
212 sq/ft width 14' 4" x depth 14' 10"
Master Bedroom:
124 sq/ft width 10' 6" x depth 11' 10"
Master Bedroom:
124 sq/ft width 10' 6" x depth 11' 10"
Master Bedroom:
126 sq/ft width 10' 8" x depth 11' 10"
Master Bedroom:
124 sq/ft width 10' 6" x depth 11' 10"
Porch - Front:
357 sq/ft width 44' 8" x depth 8'
Porch - Front:
358 sq/ft width 44' 9" x depth 8'
What's Included In This Plan Set
- Foundation plan: Most plans are available with a slab or crawlspace foundation. Optional walkout style basement (three walls masonry with a wood framed rear wall with notes for the builder to locate the windows and doors) and optional full basement foundation available if the plan allows, at an additional cost.
- Floor plans: Each home plan includes the floor plan showing the dimensioned locations of walls, doors, and windows as well as a schematic electrical layout.
- Set of elevations: All plans include the exterior elevations (front, rear, right and left) that show and describe the finished materials of the house.
- Building section(s): The building sections are vertical cuts through the house and the stairs showing floor, ceiling and roof height information. **Cross section views available for an additional fee. **
- Kitchen and bath elevations: The kitchen and bath elevations show the arrangement and size of each cabinet and other fixtures in the room. These drawings give basic information that can be used to create customized layouts with a cabinet manufacturer.
- Miscellaneous details: These are included for many interior and exterior conditions that require more specific information for their construction.
- Roof overview plan: This is a “bird’s eye” view showing the roof slopes, ridges, valleys and any saddles.
