PLAN 17-2629
Key Specs
5548
sq ft
5
Beds
4.5
Baths
2
Floors
3
Garages
Cost to Build Reports Only $19.99 for a Limited Time!
This report will provide you cost estimates based on location and building materials.
Phone: 1-888-447-1946
See our Terms & Conditions and Privacy Policy.
PLAN 17-2629
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.Plan Description
Full Specs & Features
Width : 81' 6"
Second Floor: 2272 sq/ft
Roof Framing : Conventional
Framing : Wood - 2x4
Formal Dining Room
Split Bedrooms
Family Room Keeping Room
Great Room Living Room
Media Room
3rd BR Closet:
53 sq/ft width 8' 9" x depth 6' 1"
Bathroom 2:
60 sq/ft width 11' 4" x depth 5' 4"
Bedroom 2:
210 sq/ft width 18' x depth 11' 8"
Bedroom 2 Closet:
36 sq/ft width 6' x depth 6'
Bedroom 3:
210 sq/ft width 18' x depth 11' 8"
Bedroom 3 Closet:
36 sq/ft width 6' x depth 6'
Bedroom 4:
164 sq/ft width 13' x depth 12' 8"
Bedroom 4 Closet:
17 sq/ft width 6' 10" x depth 2' 6"
Bedroom 5:
223 sq/ft width 20' x depth 11' 2"
Breakfast Room:
175 sq/ft width 13' 10" x depth 12' 8"
Den/Office or Bedroom 1:
151 sq/ft width 13' x depth 11' 8"
Dining Room:
221 sq/ft width 17' x depth 13'
Garage:
932 sq/ft width 25' 8" x depth 36' 4"
Gathering Room:
182 sq/ft width 14' x depth 13'
Hall:
width 3' 6" x depth 0"
Hall Bathroom:
68 sq/ft width 7' 3" x depth 9' 6"
Hall Closet:
29 sq/ft width 7' 4" x depth 4'
Kitchen:
248 sq/ft width 18' 8" x depth 13' 4"
Master Bathroom:
203 sq/ft width 13' x depth 15' 8"
Master Bedroom:
307 sq/ft width 20' 6" x depth 15'
Master Closet:
58 sq/ft width 7' 4" x depth 8'
Porch - Rear:
481 sq/ft width 48' 2" x depth 10'
Powder Room:
43 sq/ft width 8' 4" x depth 5' 2"
Study:
591 sq/ft width 24' 10" x depth 23' 10"
Walk-In Closet:
67 sq/ft width 7' 10" x depth 8' 8"
Wash Room:
110 sq/ft width 10' x depth 11'
