Key Specs
5752
sq ft
4
Beds
4.5
Baths
2
Floors
3
Garages
Phone: 1-888-447-1946
See our Terms & Conditions and Privacy Policy.
with Code CTB2024 (limit 1)
Residential Construction Guide
Learn Building Basics
This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.
PLAN 70-557
This plan can be customized
Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.
Plan Description
Floor Plans
Full Specs & Features
Dimension
Depth : 84' 8"
Height : 35'
Width : 121'
Area
First Floor: 4017 sq/ft
Second Floor: 1784 sq/ft
Roof
Primary Pitch : 10:12
Roof Framing : Truss
Roof Type : Shingle
Secondary Pitch : 10:12
Exterior Wall Framing
Exterior Wall Finish : Brick/Stone
Framing : 2"x6"
Bedroom Features
Main Floor Master Bedroom
Walk In Closet
Kitchen Features
Breakfast Nook
Kitchen Island
Walk In Pantry Cabinet Pantry
Additional Room Features
Den Office Study Computer
Family Room Keeping Room
Hobby Rec Room Game Room
Loft
Storage Area
Sunroom
Unfinished Future Space
Garage Features
Oversized Garage
Side Entry Garage
Lot Characteristics
Suited For Corner Lot
Suited For Sloping Lot
Suited For View Lot
Outdoor Spaces
Balcony
Screened Porch
More
Jack & Jill Bath
Rooms
Bedroom 2:
180 sq/ft width 15' x depth 12'
Bedroom 2 Closet:
36 sq/ft width 4' 6" x depth 8'
Bedroom 3:
316 sq/ft width 19' x depth 16' 8"
Bedroom 3 Closet:
36 sq/ft width 4' 6" x depth 8'
Bedroom 4:
224 sq/ft width 15' 4" x depth 14' 8"
Bedroom 4 Closet:
38 sq/ft width 5' 6" x depth 7'
Breakfast Room:
244 sq/ft width 13' 10" x depth 17' 8"
Dining Room:
210 sq/ft width 15' x depth 14'
Family Room:
399 sq/ft width 19' x depth 21'
Garage:
635 sq/ft width 29' 4" x depth 21' 8"
Garage Two:
679 sq/ft width 28' 4" x depth 24'
Kitchen:
502 sq/ft width 26' x depth 19' 4"
Laundry Room:
40 sq/ft width 5' 4" x depth 7' 8"
Living Room:
391 sq/ft width 21' 4" x depth 18' 4"
Loft:
214 sq/ft width 15' 4" x depth 14'
Master Bathroom:
297 sq/ft width 19' x depth 15' 8"
Master Bedroom:
470 sq/ft width 23' 6" x depth 20'
Master Closet:
86 sq/ft width 7' 2" x depth 12'
Master Closet Two:
86 sq/ft width 7' 2" x depth 12'
Office:
88 sq/ft width 14' 8" x depth 6'
Pantry:
53 sq/ft width 8' x depth 6' 8"
Porch - Screened:
224 sq/ft width 11' 6" x depth 19' 6"
Powder Room:
41 sq/ft width 7' 4" x depth 5' 8"
Study:
270 sq/ft width 15' x depth 18'
What's Included In This Plan Set
- Cover sheet with front rendering
- Foundation and floor plans at 1/4" = 1' scale
- Exterior elevations of all four views, front at 1/4" = 1' scale, rear and sides vary from 1/8" to 1/4" = 1' scale
- Building sections and details as required to construct the individual design
- Interior elevation of cabinets at 1/4" = 1' scale
- Roof plans
- Schematic electrical plans with suggested switch, outlet, and light fixture locations General specification design notes
- Note: Mechanical and plumbing drawings are not included. These should be obtained from a local mechanical contractor to ensure correct sizing of equipment for your region and climate conditions.
- Please note, if you are building in the state of Wisconsin, please give us a call before placing your order.
Plan Set
$2589.00
$2704.00
$3337.00
$3337.00
$5350.00
Foundation
$0.00
$395.00
$395.00
Additional Options
$395.00
$80.00
$100.00
$495.00
$39.00
$75.00
* Alternate Foundations may take time to prepare.
** Options with a fee may take time to prepare. Please call to confirm.
