PLAN 928-104

Photographs may show modified designs.

Save
  • Jump to:
  • All (7)
  • Floor plans (3)
Questions? Get Personalized Help
Home  >  Style  >  Craftsman

Key Specs


Plan Sq Ft

6145
sq ft

Plan Bedrooms

4
Beds

Plan Bathrooms

3
Baths

Plan Floors

2
Floors

Plan Garages

3
Garages

Select Plan Set Options

What's included?

Additional options

Dropdown arrow

Right-Reading Reverse
$195.00
Choose this option to reverse your plans and to have the text and dimensions readable.
Audio Video Design
$165.00
Receive an overlay sheet with suggested placement of audio and video components.
Comprehensive Material List
$495.00
A complete list of building supplies needed to construct the infrastructure of your new house, plus an overlay of materials shown directly on your PDF (foundation to rooftop with interior and exterior materials), and a detailed, itemized door and window schedule showing all sizes and types. Please allow 5-7 Business Days for completion. Note, the Comprehensive list is only available with a PDF purchase. The Comprehensive list can be ordered no matter what additional plan options you have selected.
Construction Guide
$39.00
Educate yourself about basic building ideas with these four detailed diagrams that discuss electrical, plumbing, mechanical, and structural topics.
Lighting Design
$165.00
Receive an overlay sheet with suggested placement of lighting fixtures.
Subtotal
$1995.00
Best Price Guaranteed*

Also order by phone: 1-888-447-1946

Questions about building your home?
Get Personalized Help
We do our best to get back to you within 24 - 48 business hours.
Need an answer faster? Call now...
Phone: 1-888-447-1946
Hours:
Ready for Your Call 7 Days a Week
Every Day 7 am - 8:30 pm Eastern

See our Terms & Conditions and Privacy Policy.


Wow!
Cost to Build Reports
are Only $4.99
with Code CTB2024 (limit 1)
This report will provide you cost estimates based on location and building materials.

Residential Construction Guide

Learn Building Basics

This downloadable, 26-page guide is full of diagrams and details about plumbing, electrical, and more.

PLAN 928-104

This plan can be customized

Tell us about your desired changes so we can prepare an estimate for the design service. Click the button to submit your request for pricing, or call 1-888-447-1946 for assistance.

Modify This Plan

Plan Description


Prepare to be amazed by the amenities inside this handsome family estate by Visbeen Architects. An incredibly spacious and useful kitchen leads to the bumped-out dining area, while the bright living room on the right enjoys plenty of sunshine by day and a cozy fireplace at night. Laundry rooms on both floors simplify chores. Don't miss the jaw-dropping, naturally lit walk-in closets in the master suite, or the bonus full guest apartment above the three-car garage. When finished, the lower level hosts a variety of fabulous entertainment areas. The fabulously detailed construction drawings produced by Visbeen Architects were recognized in the 2010 American Residential Design Awards.

Full Specs & Features


Dimension

Depth : 76' 2"

Height : 39' 2"

Width : 122' 7"

Area

Basement Unfinished: 2444 sq/ft height 10'

Bonus: 957 sq/ft

First Floor: 3725 sq/ft height 10'

Second Floor: 2420 sq/ft height 9'

* Total Square Footage typically only includes conditioned space and does not include garages, porches, bonus rooms, or decks.

Roof

Primary Pitch : 12:12

Roof Framing : Truss

Roof Type : Asphalt

Exterior Wall Framing

Exterior Wall Finish : Shingle/Stone

Framing : Wood - 2x6

Bedroom Features

Fireplace

Formal Dining Room

Formal Living Room / Parlor

Guest Suite

Split Bedrooms

Upstairs Master Bedrooms

Walk In Closet

Kitchen Features

Walk In Pantry Cabinet Pantry

Additional Room Features

Den Office Study Computer

Exercise Room

Family Room Keeping Room

Hobby Rec Room Game Room

Main Floor Laundry

Media Room

Unfinished Future Space

Upstairs Laundry

Garage Features

Side Entry Garage

Outdoor Spaces

Courtyard

Covered Front Porch

Covered Rear Porch

More

Jack & Jill Bath

Rooms

Bedroom 2:

164 sq/ft width 11' 4" x depth 14' 6"

Bedroom 3:

164 sq/ft width 11' 4" x depth 14' 6"

Bedroom 4:

134 sq/ft width 12' 10" x depth 10' 6"

Bedroom 5:

270 sq/ft width 14' 8" x depth 18' 5"

Bedroom 6:

432 sq/ft width 23' 6" x depth 18' 5"

Billiards Room:

251 sq/ft width 14' 1" x depth 17' 10"

Dining Room:

225 sq/ft width 15' x depth 15'

Exercise Room:

432 sq/ft width 23' 6" x depth 18' 5"

Family Room:

667 sq/ft width 18' 8" x depth 35' 9"

Garage:

840 sq/ft width 35' x depth 24'

Guest Suite:

405 sq/ft width 20' x depth 20' 3"

Kitchen:

373 sq/ft width 20' 2" x depth 18' 6"

Living Room:

576 sq/ft width 19' x depth 30' 4"

Master Bedroom:

220 sq/ft width 12' 10" x depth 17' 2"

Office:

136 sq/ft width 13' x depth 10' 6"

Study:

222 sq/ft width 13' 6" x depth 16' 6"
